Introduction
Ladhani Metal Corporation is a leading manufacturer, supplier, and exporter of
stainless steel sheets, plates, and coils manufactured as per IS 6911
standards. These products are designed to meet stringent mechanical, thermal,
and corrosion resistance requirements for use in industries such as power
generation, chemical processing, oil and gas, petrochemical, shipbuilding, and
heavy engineering. Our stainless steel sheet, plate, and coil products are
available in a wide range of EN/DIN designations, ensuring suitability for both
high-strength and corrosion-resistant applications.
What is IS 6911 Stainless Steel Sheet, Plate and Coil?
IS 6911 is the Indian Standard specification that governs the chemical
composition, mechanical properties, and quality requirements for stainless
steel sheets, plates, and strips. These materials are produced through hot
rolling or cold rolling processes and supplied in annealed, pickled, polished,
or coated conditions depending on the application. IS 6911 stainless steels are
widely used in environments that demand high strength, toughness, resistance to
scaling, and resistance to corrosive media.
Purpose and Functionality
Stainless steel sheets, plates, and coils under IS 6911 are used to fabricate
equipment, components, and structures where long-term durability, resistance to
oxidation, and mechanical stability are critical. Their functionality extends
across multiple industries by serving as raw material for pressure vessels,
heat exchangers, storage tanks, boilers, pipelines, and structural parts.
Depending on the grade, these products provide specific combinations of
hardness, ductility, weldability, and corrosion resistance.
Key Features
· Manufactured to IS 6911 specifications with strict quality control
· Available in hot rolled, cold rolled, and polished finish
· Excellent resistance to oxidation and scaling at high temperatures
· Wide range of grades for diverse industrial applications
· High mechanical strength and toughness
· Suitable for forming, machining, and welding operations
· Supplied in sheets, plates, and coils of various dimensions
Material Grades Offered by Ladhani Metal Corporation
We supply IS 6911 stainless steel sheets, plates, and coils in the following IS designations:
· X04Cr12
· X07Cr17
· X12Cr12
· X20Cr13
· X30Cr13
· X40Cr13
· X15Cr16Ni2
· X108Cr17Mo
· X10Cr17Mn6Ni4N2O
· X07Cr11Mn12Ni4
· X10Cr18Mn9Ni5
· X30Cr17Ni7
· X07Cr18Ni9
· X04Cr19Ni9
· X02Cr19Ni10
· X15Cr24Ni13
· X20Cr25Ni20
· X04Cr17Ni12Mo2
· X02Cr17Ni12Mo2
· X04Cr17Ni12Mo2Ti
· X04Cr18Ni10Ti
· X04Cr18Ni10Nb
Chemical Composition of the Following Grades
X04Cr12
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 11.5 – 13.5%
• Iron (Fe): Balance
X07Cr17
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Iron (Fe): Balance
X12Cr12
• Carbon (C): ≤ 0.15%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 11.0 – 13.0%
• Iron (Fe): Balance
X20Cr13
• Carbon (C): ≤ 0.20%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 12.0 – 14.0%
• Iron (Fe): Balance
X30Cr13
• Carbon (C): ≤ 0.35%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 12.0 – 14.0%
• Iron (Fe): Balance
X40Cr13
• Carbon (C): ≤ 0.45%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 12.5 – 14.5%
• Iron (Fe): Balance
X15Cr16Ni2
• Carbon (C): ≤ 0.15%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 1.50%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 15.0 – 17.0%
• Nickel (Ni): 1.5 – 2.5%
• Iron (Fe): Balance
X108Cr17Mo
• Carbon (C): 0.95 – 1.15%
• Silicon (Si): ≤ 0.60%
• Manganese (Mn): ≤ 0.60%
• Phosphorus (P): ≤ 0.030%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Molybdenum (Mo): 0.20 – 0.50%
• Iron (Fe): Balance
X10Cr17Mn6Ni4N2O
• Carbon (C): ≤ 0.12%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): 5.0 – 7.0%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Nickel (Ni): 3.5 – 4.5%
• Nitrogen (N): 0.10 – 0.20%
• Iron (Fe): Balance
X07Cr11Mn12Ni4
• Carbon (C): ≤ 0.10%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): 11.0 – 13.0%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 10.0 – 12.0%
• Nickel (Ni): 3.5 – 4.5%
• Iron (Fe): Balance
X10Cr18Mn9Ni5
• Carbon (C): ≤ 0.12%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): 8.0 – 10.0%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 17.0 – 19.0%
• Nickel (Ni): 4.0 – 6.0%
• Iron (Fe): Balance
X30Cr17Ni7
• Carbon (C): ≤ 0.35%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.040%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Nickel (Ni): 6.0 – 8.0%
• Iron (Fe): Balance
X07Cr18Ni9
• Carbon (C): ≤ 0.10%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 17.0 – 19.0%
• Nickel (Ni): 8.0 – 10.0%
• Iron (Fe): Balance
X04Cr19Ni9
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 18.0 – 20.0%
• Nickel (Ni): 8.0 – 10.5%
• Iron (Fe): Balance
X02Cr19Ni10
• Carbon (C): ≤ 0.03%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 17.5 – 19.5%
• Nickel (Ni): 9.0 – 11.0%
• Iron (Fe): Balance
X15Cr24Ni13
• Carbon (C): ≤ 0.15%
• Silicon (Si): ≤ 1.50%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.035%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 23.0 – 26.0%
• Nickel (Ni): 12.0 – 14.0%
• Iron (Fe): Balance
X20Cr25Ni20
• Carbon (C): ≤ 0.20%
• Silicon (Si): ≤ 1.50%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.035%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 24.0 – 26.0%
• Nickel (Ni): 19.0 – 21.0%
• Iron (Fe): Balance
X04Cr17Ni12Mo2
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Nickel (Ni): 11.0 – 13.0%
• Molybdenum (Mo): 2.0 – 2.5%
• Iron (Fe): Balance
X02Cr17Ni12Mo2
• Carbon (C): ≤ 0.03%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.5 – 18.5%
• Nickel (Ni): 10.5 – 13.0%
• Molybdenum (Mo): 2.0 – 2.5%
• Iron (Fe): Balance
X04Cr17Ni12Mo2Ti
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 16.0 – 18.0%
• Nickel (Ni): 11.0 – 13.0%
• Molybdenum (Mo): 2.0 – 2.5%
• Titanium (Ti): ≥ 5×C and ≤ 0.70%
• Iron (Fe): Balance
X04Cr18Ni10Ti
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 17.0 – 19.0%
• Nickel (Ni): 9.0 – 11.0%
• Titanium (Ti): ≥ 5×C and ≤ 0.70%
• Iron (Fe): Balance
X04Cr18Ni10Nb
• Carbon (C): ≤ 0.08%
• Silicon (Si): ≤ 1.00%
• Manganese (Mn): ≤ 2.00%
• Phosphorus (P): ≤ 0.045%
• Sulfur (S): ≤ 0.030%
• Chromium (Cr): 17.0 – 19.0%
• Nickel (Ni): 9.0 – 11.0%
• Niobium (Nb): ≥ 10×C and ≤ 1.00%
• Iron (Fe): Balance
Applications
IS 6911 stainless steel sheets, plates, and coils are used across various
applications, including:
· Boilers and heat exchangers
· Pressure vessels and storage tanks
· Power plant equipment
· Petrochemical and refinery piping systems
· Food processing and pharmaceutical equipment
· Structural components for marine and industrial use
· Automotive exhaust systems
Manufacturing Capabilities
Ladhani Metal Corporation employs hot rolling, cold rolling, annealing,
pickling, polishing, and surface finishing techniques to manufacture IS 6911
stainless steel sheets, plates, and coils. Products are available in
thicknesses ranging from 0.3 mm to 120 mm, widths up to 2500 mm, and customized
lengths or coil form.
Conclusion
Ladhani Metal Corporation is a Manufacturer, Supplier, and Exporter of IS 6911
Stainless Steel Sheets, Plates, and Coils. Our products are manufactured to the
highest standards of precision and quality, ensuring long-lasting performance
in challenging industrial environments.
For technical data, price inquiries, or customized requirements, contact us
at info@ladhanimetals.com or visit https://www.ladhanimetal.in/
