Introduction
EN
10028-4 covers flat products made of nickel alloy steels for pressure purposes.
These steels are designed for pressure equipment requiring good toughness and
reliable mechanical performance, particularly at low and sub-zero temperatures.
EN
10028-4 nickel alloy steel sheets and plates are used in pressure vessels,
storage tanks, chemical processing equipment, cryogenic and low-temperature
equipment, oil and gas facilities, and other pressure-containing applications.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of EN 10028-4
Nickel Alloy Steel Sheet & Plate, supplying pressure vessel plates in
various grades, thicknesses, widths, lengths, heat-treatment conditions,
surface finishes, and customized dimensions worldwide.
Applicable Standard
Standard
Specification: EN 10028-4
Organization:
European Committee for Standardization (CEN)
Title:
Flat Products Made of Steels for Pressure Purposes – Part 4: Nickel Alloy
Steels with Specified Low Temperature Properties
EN
10028-4 specifies nickel alloy steel flat products intended for pressure
equipment and applications requiring specified low-temperature properties.
Material Type
•
Nickel Alloy Steel
• Low-Temperature Pressure Vessel Steel
• Alloy Steel
• Pressure Vessel Steel
• Fine-Grain Nickel Alloy Steel
• Low-Temperature Service Steel
Forms of Supply
•
Nickel Alloy Steel Sheets
• Nickel Alloy Steel Plates
• Pressure Vessel Plates
• Low-Temperature Steel Plates
• Heat Exchanger Plates
• Hot Rolled Plates
• Cut-to-Length Plates
• Custom Cut Sheets
Grades Covered
Under EN 10028-4
13MnNi6-3
| 12Ni14 | 15NiMn6 | 12Ni19 | 11MnNi5-3
Supply Condition
•
Normalized Condition
• Normalized and Tempered Condition
• Quenched and Tempered Condition
• Heat Treated Condition
• Stress Relieved Condition
• Hot Rolled Condition
Surface Finish
•
Hot Rolled Finish
• Mill Finish
• Shot Blasted Finish
• Pickled Finish
• Smooth Finish
• Descaled Finish
Standard Sizes
Nickel Alloy Steel Sheets & Plates
Thickness:
3 mm to 250 mm
Width:
Up to 3,500 mm
Length:
Up to 12,000 mm
Custom
thicknesses, widths, lengths, cut-to-size plates, edge conditions, and surface
finishes are available according to customer requirements.
Chemical
Composition of EN 10028-4
|
Steel
name |
C
max. |
Si
max. |
Mn |
P
max. |
S
max. |
Al_total
min. |
Mo
max. |
Nb
max. |
Ni |
V
max. |
|
11MnNi5-3 |
0.14 |
0.50 |
0.70–1.50 |
0.025 |
0.010 |
0.020 |
– |
0.05 |
0.30–0.80 |
0.05 |
|
13MnNi6-3 |
0.16 |
0.50 |
0.85–1.70 |
0.025 |
0.010 |
0.020 |
– |
0.05 |
0.30–0.85 |
0.05 |
|
15NiMn6 |
0.18 |
0.35 |
0.80–1.50 |
0.025 |
0.010 |
– |
– |
– |
1.30–1.70 |
0.05 |
|
12Ni14 |
0.15 |
0.35 |
0.30–0.80 |
0.020 |
0.005 |
– |
– |
– |
3.25–3.75 |
0.05 |
|
X12Ni5 |
0.15 |
0.35 |
0.30–0.80 |
0.020 |
0.005 |
– |
– |
– |
4.75–5.25 |
0.05 |
|
X8Ni9 |
0.10 |
0.35 |
0.30–0.80 |
0.020 |
0.005 |
– |
0.10 |
– |
8.5–10.0 |
0.05 |
|
X7Ni9 |
0.10 |
0.35 |
0.30–0.80 |
0.015 |
0.005 |
– |
0.10 |
– |
8.5–10.0 |
0.01 |
Notes:
a. Elements not listed in
this table shall not be intentionally added to the steel without the agreement
of the purchaser, except for finishing the cast. All appropriate measures shall
be taken to prevent the addition from scrap or other materials used in
steelmaking of these elements which may adversely affect the mechanical
properties and usability. The content of Cr + Cu + Mo shall not exceed 0.50%.
b. For nominal thicknesses ≤
40 mm, a minimum nickel content of 0.15% is permitted.
Key Features of EN
10028-4 Steel Sheet & Plate
•
Excellent low-temperature toughness
• Good mechanical strength
• Good weldability
• High resistance to brittle fracture
• Reliable pressure-bearing performance
• Fine-grain structure
• Good dimensional stability
• Suitable for low-temperature service
• Excellent fabrication characteristics
• Long service life
Applications of EN
10028-4 Steel Sheet & Plate
Pressure Vessel Industry
•
Pressure Vessels
• Storage Tanks
• Process Vessels
• Low-Temperature Pressure Equipment
• High-Pressure Equipment
Oil & Gas Industry
•
Oil Storage Tanks
• Gas Processing Equipment
• LNG-Related Equipment
• Pressure Vessels
• Hydrocarbon Processing Equipment
Petrochemical Industry
•
Process Vessels
• Storage Equipment
• Heat Exchangers
• Refinery Equipment
• Low-Temperature Processing Equipment
Chemical Industry
•
Chemical Storage Tanks
• Process Equipment
• Pressure Vessels
• Reactor Equipment
• Low-Temperature Chemical Equipment
Industrial Applications
•
Low-Temperature Equipment
• Cryogenic-Related Equipment
• Industrial Storage Tanks
• Pressure Equipment
• Heavy Engineering Components
Fabrication and
Welding
EN
10028-4 nickel alloy steel plates provide good welding and fabrication
characteristics when appropriate procedures are followed.
•
Suitable for welding
• Good bending characteristics
• Suitable for forming
• Good machining characteristics
• Good resistance to brittle fracture
• Suitable for pressure vessel fabrication
• Reliable welded joint performance
Welding
procedures, preheating, interpass temperatures, and post-weld heat treatment
should be selected according to the specific grade and plate thickness.
Heat Treatment
Heat
treatment depends on the selected EN 10028-4 grade.
•
Normalizing refines the grain structure
• Tempering improves toughness
• Quenching and tempering increases strength
• Controlled cooling provides uniform properties
• Stress relieving reduces residual stresses
• Proper heat treatment improves low-temperature performance
Advantages of EN
10028-4 Steel Sheet & Plate
•
Excellent low-temperature performance
• High resistance to brittle fracture
• Good mechanical strength
• Good weldability
• Suitable for pressure vessels
• Excellent toughness
• Reliable performance in sub-zero conditions
• Suitable for demanding oil and gas applications
• Good dimensional accuracy
• Long operational service life
Conclusion
EN
10028-4 Steel Sheet & Plate covers nickel alloy steels for pressure
purposes with specified low-temperature properties. The grades 13MnNi6-3,
12Ni14, 15NiMn6, 12Ni19, and 11MnNi5-3 are designed to provide reliable
strength, toughness, weldability, and resistance to brittle fracture for
pressure equipment operating at low temperatures.
Ladhani Metal Corporation supplies EN
10028-4 Nickel Alloy Steel Sheet & Plate in various grades, thicknesses,
widths, lengths, heat-treatment conditions, surface finishes, and customized
dimensions for pressure vessels, storage tanks, oil and gas equipment,
petrochemical plants, chemical processing equipment, and low-temperature
industrial applications worldwide.
