Introduction
EN 10025-2
is a European standard that specifies non-alloy structural steels supplied in
hot-rolled condition. These steels are widely used for general structural and
engineering applications where good strength, weldability, and toughness are
required. EN 10025-2 grades are commonly supplied in the form of plates,
sheets, coils, and strips and are suitable for fabrication, construction, and
mechanical structures.
The standard
defines multiple grades based on minimum yield strength and impact test
requirements at different temperatures. EN 10025-2 structural steels offer an
excellent balance of mechanical strength, formability, and cost-effectiveness,
making them one of the most widely used structural steel standards globally.
Applicable
Standards and Specifications
Standard: EN
10025-2
Material Type: Non-alloy structural steel
Product Forms: Plates, sheets, coils, strips
Manufacturing Process: Hot Rolled (HR)
Delivery Condition: As rolled (+AR) or Normalized / Normalized Rolled (+N)
EN 10025-2
materials are commonly used in accordance with European construction and
fabrication codes and are accepted worldwide.
Available
Grades of EN 10025-2 Structural Steel
EN 10025-2
includes the following grades, classified by minimum yield strength and impact
test requirements:
S235JR, S235J0, S235J2
S275JR, S275J0, S275J2
S355JR, S355J0, S355J2
JR grades
are tested at +20°C, J0 grades at 0°C, and J2 grades at −20°C for impact
toughness.
Chemical Composition of EN 10025-2 Grades (%)
S235JR /
S235J0 / S235J2 Chemical Composition
|
Element |
Composition (%) |
|
Carbon (C) |
0.17 max |
|
Manganese
(Mn) |
1.40 max |
|
Phosphorus
(P) |
0.035 max |
|
Sulfur (S) |
0.035 max |
|
Nitrogen
(N) |
0.012 max |
|
Copper
(Cu) |
0.55 max |
Note: JR,
J0, and J2 grades have the same chemical composition; the difference lies in
impact test temperature requirements.
S275JR /
S275J0 / S275J2 Chemical Composition
|
Element |
Composition (%) |
|
Carbon (C) |
0.21 max |
|
Manganese
(Mn) |
1.50 max |
|
Phosphorus
(P) |
0.035 max |
|
Sulfur (S) |
0.035 max |
|
Nitrogen
(N) |
0.012 max |
|
Copper
(Cu) |
0.55 max |
S355JR /
S355J0 / S355J2 Chemical Composition
|
Element |
Composition (%) |
|
Carbon (C) |
0.24 max |
|
Manganese
(Mn) |
1.60 max |
|
Phosphorus
(P) |
0.035 max |
|
Sulfur (S) |
0.035 max |
|
Nitrogen
(N) |
0.012 max |
|
Copper
(Cu) |
0.55 max |
Mechanical
Properties of EN 10025-2 Structural Steel
Minimum
mechanical properties for plates and sheets:
|
Grade |
Yield
Strength (MPa) |
Tensile Strength (MPa) |
Elongation (%) |
|
S185 |
≥ 185 |
290 – 410 |
≥ 20 |
|
S235 |
≥ 235 |
360 – 510 |
≥ 26 |
|
S275 |
≥ 275 |
410 – 560 |
≥ 23 |
|
S355 |
≥ 355 |
470 – 630 |
≥ 22 |
Impact test
requirements:
JR grades:
27 J at +20°C
J0 grades: 27 J at 0°C
J2 grades: 27 J at −20°C
Physical
Properties (Typical)
Density:
approximately 7.85 g/cm³
Melting Point: approximately 1425 – 1540°C
Thermal Conductivity: approximately 50 – 60 W/m·K
Modulus of Elasticity: approximately 200 GPa
Thickness,
Width, and Size Range
Thickness:
1.5 mm to 200 mm
Width: up to 3000 mm
Length: up to 12000 mm or as per customer requirement
Material can
be supplied as plates, sheets, coils, or strips in cut-to-size or slit
condition.
Key Features
and Advantages
Excellent
weldability without special preheating in most cases
Good formability and machinability
Consistent mechanical properties
Wide availability and cost-effective
Suitable for large-scale structural fabrication
Compliance with European construction standards
Weldability
and Fabrication
EN 10025-2
structural steels exhibit very good weldability due to controlled carbon
content. Standard welding processes such as SMAW, GMAW, FCAW, and SAW can be
used. For thicker sections and higher grades like S355, controlled heat input
and low-hydrogen consumables are recommended.
The material
is easy to cut, bend, roll, and form using conventional fabrication methods.
Corrosion
Resistance
EN 10025-2
steels provide limited corrosion resistance and are best suited for indoor or
protected environments. For outdoor or aggressive conditions, surface protection
such as painting, galvanizing, or coating is recommended.
Applications
of EN 10025-2 Structural Steel
EN 10025-2
structural steels are extensively used across construction, infrastructure, and
engineering industries due to their excellent strength, weldability, toughness,
and fabrication flexibility. The availability of multiple grades allows
engineers to select the most suitable material based on load requirements,
environmental conditions, and service temperature.
Building and
Structural Construction
EN 10025-2
steels are widely used in residential, commercial, and industrial building
structures where reliability and load-bearing capability are essential.
Typical uses
include:
Structural beams and columns
Girders and trusses
Floor plates and decking
Staircases and platforms
Roofing and support frames
Grades such
as S235 and S275 are commonly used for light to medium structural applications,
while S355 is preferred for heavy-load structures and high-rise buildings.
Bridges and
Infrastructure Projects
EN 10025-2
steels are extensively employed in infrastructure projects that require
strength, toughness, and long service life.
Common
applications include:
Road and railway bridges
Pedestrian bridges and walkways
Flyovers and underpasses
Metro and rail infrastructure
Expansion joints and structural supports
For bridges
and exposed structures, J0 and J2 grades are preferred due to their improved
impact toughness at lower temperatures.
Industrial
Structures and Plants
EN 10025-2
steel plates and sections are used in a wide range of industrial facilities and
production plants.
Applications
include:
Industrial sheds and warehouses
Power plant structures
Cement plant frameworks
Refinery and process plant structures
Pipe racks and equipment supports
S355 grade
is widely used in industrial environments where higher strength and reduced
section thickness are required.
General
Fabrication and Engineering
Due to
excellent formability and weldability, EN 10025-2 steels are ideal for general
fabrication work.
Typical
fabricated products include:
Base plates and mounting plates
Brackets, frames, and supports
Machine beds and structural frames
Fabricated steel components
Lifting and handling structures
These steels
allow easy cutting, bending, drilling, and welding without special processing
requirements.
Heavy
Engineering and Machinery
EN 10025-2
structural steels are used in heavy engineering and machinery manufacturing
where moderate strength and durability are required.
Common
applications include:
Machinery frames and housings
Cranes and material handling equipment
Conveyors and support structures
Construction equipment components
S355 grade
is commonly selected for heavy machinery due to its higher yield strength.
Transportation
and Logistics Infrastructure
EN 10025-2
steels play a key role in transportation and logistics infrastructure.
Applications
include:
Truck and trailer chassis components
Container frames and platforms
Railway wagons and structural parts
Loading bays and docking structures
The
toughness and strength of EN 10025-2 steels ensure reliable performance under
dynamic loads.
Energy and
Power Sector
EN 10025-2
steels are widely used in non-pressure components within the energy sector.
Typical uses
include:
Power plant structural frameworks
Wind turbine towers and platforms
Solar power mounting structures
Transmission towers and substations
J2 grades
are often used in outdoor installations where low-temperature toughness is
required.
Storage
Tanks and Non-Pressure Vessels
While EN
10025-2 is not intended for pressure vessels, it is commonly used in
non-pressure storage applications.
Applications
include:
Water tanks and reservoirs
Fuel and oil storage tanks (non-pressure)
Silos and hoppers
Material storage containers
S235 and
S275 grades are typically used due to their good formability and weldability.
Marine and
Coastal Structures
EN 10025-2
steels are used in marine and coastal environments when combined with suitable
corrosion protection.
Applications
include:
Port structures and jetties
Offshore platforms (secondary structures)
Shipbuilding structural components
Marine walkways and access platforms
Protective
coatings and corrosion control systems are recommended for long-term service.
Conclusion
EN 10025-2
Structural Steel Plate / Sheet is a versatile and widely used material for
construction, fabrication, and engineering applications. Its combination of
strength, weldability, toughness, and economic value makes it a preferred
choice for structural projects worldwide. When properly fabricated and
protected, EN 10025-2 steel delivers reliable performance and long service life
across a broad range of applications.
For customized sizes, bulk supply, or technical support, contact Ladhani Metal Corporation
