Name: Grade 5 Titanium Alloy Rod
Availability: instock

Place of Origin: India Product Name: Titanium Anode Basket Grade:Gr1 Gr2 Titanium Ti Content :99.6% Certificate: ISO 9001:2015 Surface Treatment: polished Size: according to customer Features Toughness, light weight,Stability dimension Lower electricity consumption,high catalytic Strong corrosion resistance,long working life High property of acid and alkali resistance, Bear high & low temperature, etc. Titanium anode basket is composed of a titanium plate and a titanium mesh, and the thickness of the titanium ranges between 0.5-2mm. Common meshes for titanium baskets are 6mm×3mm, 10mm×3mm, 10mm×5mm, and wider ones are 16mm×8mm, 25mm×15mm, etc. It is usuall used for Sewage treatment,Electroplating Industry,Cathode protection,Noble metal plating (silver, gold),Electrolytic water,Sea water antifouling,Electrolytic syn thesis of organic,Testing electrode,Electrodialysis etc. Product name Titanium baskets Material grade Gr1 / Gr2 Titanium Ti Content 99.6% Min Certificate En 10204/3.1 Surface treatment Pickled, polished Size According to customer MOQ 3 Pieces Production Method: Cutting Welding Bending Hooks of Titanium Anode Baskets Titanium hooks in inverted “V”, “U” or reverse hooks for easier lift Copper hooks for high amperage option Mesh Panels Perforated or expanded mesh panels Spot and TIG welded completely to side channel, horizontal and vertical reinforcing bands. Mesh on four sides of basket for greater anode-to-cathode ratio Our titanium anode baskets are fabricated from the purest grade of titanium and are very durable. All of our baskets are spot welded and TIG welded with full argon gas shielding to ensure structural integrity.

Send Message

Grade 5 Titanium Alloy Rod

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Unit Price: $15usd/kg- $30usd/kg Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright Grade 5 Titanium Alloy Rod Our Advantages 1. Price: As a leading manufacturer of titanium products, we have a history of more than 16 years and we know the market very well, so competitive prices can be offered. 2. Equipment: We have annealing furnaces, forging hammers, milling machines, straightening machines, shearing machines, trimming machines, punching machines, sandblasting machines etc. 3. Quality: Our titanium rods are sold to many countries. Our product is widely recognized. MTC, like EN10204.3.1, is available. Third-party test, such as TUV, SGS, BV etc., is also acceptable. 4. Shipment: Various modes of shipping. EXW, FOB, CIF etc. are all ok for us. Applications Petrochemical industry Desalination Seawater pipelines Offshore oil drilling Mariculture Precision parts Aerospace Medical industry Metallury Power industry Shipbuilding Bridges Vaccum salt production Light industry Mechanical equipment Electronics

Send Message

Grade 12 Titanium Alloy Bar 30mm

Product Name: Grade 12 Titanium alloy Bar 30mm Standard: ASTM B348 Material: GR12 Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright Unit price:$21.5-$34.9/kg Product Description Product Grade 12 Titanium Alloy Bar 30mm Technique Rolled, Forged Grade GR12 titanium Russian Grade BT1-00,BT1-0,BT1-2 Standard ASTM B348, AMS 4928 Shape Round, Square, Flat, Hex Diameter 3-350mm Length up to 6000mm Surface Bright Product Certificate En10204/3.1 Company certificate ISO 9001:2015 gr12 titanium bar Other grade titanium bar: Gr1 titanium bar/rod Gr2 titanium bar/rod Gr3 titanium bar/rod Gr4 titanium bar/rod Gr5 titanium bar/rod Gr7 titanium bar/rod etc.

Send Message

Gr2 Titanium Pipe For Heat Exchanger

Product Name: Titanium Pipe Standard: ASTM B338 Material: Gr1, Gr2 Unit Price: $25usd/kg-$40usd/kg Type: Welded/Seamless Shape: Round Outer Diameter: 9.52mm/12.7mm/15.9mm/19mm/21.7mm/25.4mm/32mm/33.4mm/38mm/45mm etc. Wall Thickness: 0.5-3.0mm Length: Max 12000mm Surface: Bright Product Information Titanium pipe is light in weight, high in strength and superior in mechanical properties. It is widely used in heat exchange equipment, such as tube and tube heat exchangers, coil heat exchangers, serpentine tube heat exchangers, condensers, evaporators and transportation pipelines. Many nuclear power industries use titanium pipes as standard pipes for their units

Send Message

Gr12 Titanium Seamless Tube

Product Name: Gr12 Titanium Seamless Tube Standard: ASTM B337,ASTM B338,ASTM B861, ASTM B862 Material: Titanium Gr12 Unit Price: $25usd/kg-$40usd/kg Type: Welded/Seamless Shape: Round Outer Diameter: 3-508mm Wall Thickness: 0.1-20mm Length: Max 12000mm Surface: Bright Gr12 Titanium Seamless Tube Titanium tubes have been widely used in chemical, petroleum, petrochemical, vacuum salt making, preparation, marine engineering, electric power and other industries. Titanium is widely used in corrosive media due to its good corrosion resistance, such as ionic membrane caustic soda, propylene oxide, etc. titanium materials are widely used in equipment and pipelines. Product media are also used in formic acid, methane chloride and other projects to solve pipeline corrosion problems. Place of Origin:Shaanxi, China Material:ASTM B337,ASTM B338,ASTM B861, ASTM B862 Outer Diameter:3-508mm Wall Thickness:0.2-20mm Length:Max 15Meter Standard:ASTM B861 Application:Industrial Technique:Seamless Grade:Titanium Alloy Key Words:titanium tube Type:Titanium Round Tube Certificates:SO9001:2015 Processing:Drawing Surface:Bright Finished Shape:Round.square.Rectangle Package:plywood Case Titanium grade 12 pipe (Ti-0.3Mo-0.8Ni) Chemical compositions(weight%,<=) Mo Ni Fe C N 0.2-0.4 0.6-0.9 0.30 0.08 0.03 H O Ti Others Total 0.015 0.25 Remainder 0.10 0.40 Physical properties(>=) Σb Tensile Strength (Mpa) σr0.2 Yield Strength (Mpa) δL0+50mm Elongation (%) ψ Reduction of area (%) 440 345 18 ------- Titanium is widely used in chemical industry because of its high strength, light weight, good heat transfer performance and corrosion resistance. These characteristics of titanium make it a relatively economic method to solve engineering problems related to chemical industry. Although the investment cost of titanium is higher than that of general performance materials, titanium has been widely used in the chemical industry. According to the life cycle analysis, using it can reduce the production cost by reducing maintenance, shortening downtime, increasing product quality and increasing product life.

Send Message

Titanium Alloy Tubes

Product name: Titanium alloy Tubes Standard:ASTM B338 ASTM B861 ASTM B862 Material:Titanium Gr7 Diameter:5-914mm Wall thickness:0.5-50mm Length:Max 16000mm Surface:Pickling surface/Polished Type:Seamless, welded Application:Heat Exchanger, chemical industry etc. Technique:Rolled Because stainless steel and other materials are inefficient in many cases, titanium tubes are increasingly used in various occasions. A common titanium grinding product is titanium tube. Because of its superior corrosion resistance and strength weight ratio, titanium tube is used in various products. The development of many different alloys has expanded the application of titanium in industry, chemical processing and power generation. Commodity Titanium Alloy Tube /Pipe/Tubing,titanium alloy seamless tube/pipe,titanium alloy welded tube pipe,ASTM B338 titanium tube,Titanium pipe price per kg Tube Shape Round Square Flat Coil Material Gr1,Gr2,Gr3,Gr4,Gr5(Ti-6Al-4V),Gr7,Gr9,Gr11,Gr12,Gr23(Ti-6Al-4V Eli) Standard ASTM B337 ASTM B338 ASTM B861 ASTM B862 Type Seamless Welded ERW Fabricated OD 5-914mm or as customized Wall Thickness 0.5-50mm or as customized Length Max 16000mm End Plain End, Beveled End, Threaded Certificate EN 10204/3.1B, Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc Application Off-Shore Oil Drilling Companies Power Generation Petrochemicals Gas Processing Specialty Chemicals Pharmaceuticals Pharmaceutical Equipment Chemical Equipment Sea Water Equipment Heat Exchangers Condensers Pulp and Paper Industry Titanium alloy tubes can be divided into three categories according to phase composition: α Alloy（ α+β) Alloy and β alloy 1. α Stability of alloy containing a certain amount α The element of phase, in equilibrium, is mainly composed of α Phase composition. α The alloy has small specific gravity, good thermal strength, good weldability and excellent corrosion resistance. Its disadvantage is low strength at room temperature. It is usually used as heat-resistant and corrosion-resistant materials. α Alloys can usually be divided into complete alloys α Alloy (Gr7), near α Alloy (ti-8al-1mo-1v) and alloy with a small amount of compounds α Alloy (Ti-2.5Cu). 2. ( α+β) Stability of alloy containing a certain amount α Phase harmony β Phase elements, and the microstructure of the alloy in equilibrium is α Phase harmony β Phase. ( α+β) The alloy has medium strength and can be strengthened by heat treatment, but its weldability is poor. ( α+ β) Alloys are widely used, and the output of Ti-6Al-4V Alloy accounts for more than half of all titanium materials. 3. β The alloy contains a large amount of stable β Phase elements can be used at high temperature β All phases were retained to room temperature. β Alloys can usually be divided into heat treatable alloys β Alloy (metastable) β Alloy and near metastable β Alloy) and thermal stability β Alloy. Heat treatable β The alloy has excellent plasticity in quenched state, and the tensile strength can reach 130 ~ 140kgf / mm2 by aging treatment. β Alloys are usually used as high strength and high toughness materials. The disadvantages are large ratio, high cost, poor welding performance and difficult machining.

Send Message

Titanium Bars Grade 1

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright Product Information Standard: ASTM B348, AMS 4928, ASTM F67,ASTM F136 Grade: GR1, GR2, GR4, GR5, GR5 ELI, GR7, GR12, GR23, TC11, TC21, Ti-15333, Ti-662 etc. Russian Grade: BT1-100,BT1-0,BT6 etc. Shape: Round, Square, Flat, Hex Diameter: 3-350mm Length: up to 6000mm, random length is also ok and the price is lower Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per your requirements Surface: Polishing, Pickling Condition: R/M/Y Features: 1. Not any defects free from cracks no pitting. 2. Two ends flatting making sure length tolerance and good looking. Applications: water treatment, desalination, power generation, marine, aerospace, chemical processing, engine components, autometic parts, medical industry, sports equipment etc. Dia （mm） Weight per meter （kg） Dia （mm） Weight per meter （kg） Dia （mm） Weight per meter （kg） Dia （mm） Weight per meter （kg） 6 0.13 30 3.19 54 10.33 78 21.55 7 0.17 31 3.40 55 10.71 79 22.11 8 0.23 32 3.63 56 11.11 80 22.67 9 0.29 33 3.86 57 11.51 81 23.24 10 0.35 34 4.09 58 11.92 82 23.82 11 0.43 35 4.34 59 12.33 83 24.40 12 0.51 36 4.59 60 12.75 84 24.99 13 0.60 37 4.85 61 13.18 85 25.59 14 0.69 38 5.11 62 13.62 86 26.20 15 0.80 39 5.39 63 14.06 87 26.81 16 0.91 40 5.67 64 14.51 88 27.43 17 1.02 41 5.95 65 14.96 89 28.06 18 1.15 42 6.25 66 15.43 90 28.69 19 1.28 43 6.55 67 15.90 91 29.33 20 1.42 44 6.86 68 16.38 92 29.98 21 1.56 45 7.17 69 16.86 93 30.63 22 1.71 46 7.49 70 17.36 94 31.30 23 1.87 47 7.82 71 17.86 95 31.97 24 2.04 48 8.16 72 18.36 96 32.64 25 2.21 49 8.50 73 18.88 97 33.33 26 2.39 50 8.86 74 19.40 98 34.02 27 2.58 51 9.21 75 19.92 99 34.72 28 2.78 52 9.58 76 20.46 100 35.42 29 2.98 53 9.95 77 21.00

Send Message

Titanium Jig Rack For Anodizing

Product Name: Titanium Finger Jigs Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished We can provide various customized titanium hangers made of high-quality pure titanium (GR1, Gr2). The titanium jigs/racks produced by our factory has good elasticity and strong corrosion resistance. It adopts precision welding technology, and the welded junction is closely and firmly combined. We can recommend to customers according to the products we have made before, also can produce them according to customers' drawings! Product Name:Titanium Jig Rack For Anodizing Material: Pure titanium Gr1, Gr2 Size: Customized Surface: Polished Number of hanging teeth:customized Application: Electroplating, anodizing etc. Chemical composition (Wt%) ASTM No. Fe max O max N max C max H max Pd Al Bal Grade 1 0.2 0.18 0.03 0.1 0.015 - - Ti Grade 2 0.3 0.25 0.03 0.1 0.015 - - Ti Physical Properties (Min) ASTM Grade Alloy Composition Tensile Strength Yield Strength Elongation min % ksi Mpa ksi Mpa Grade 1 Unalloyed Ti ("Pure") 35A -CP1 35 240 25 170 30 Grade 2 Unalloyed Ti ("Pure") 50A -CP2 58 400 40 275 25

Send Message

Titanium Bar

TC11 Titanium Alloy Bar

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright TC11 Titanium Alloy Bar As an important material for aerospace, TC11 is an α+β dual-phase titanium alloy with the phasetransfer temperature between 998 and 1020°C. Due to its excellent properties (such as high strength and fatigue resistance), it has become an ideal material to produce aircraft engine parts. TC11 titanium alloy under 300°C/5000 h has good microstructure and performance stability, different temperature transient high-temperature properties, such as tensile, creep and lasting, and double annealing and isothermal annealing. Through the normal annealing treatment of semi-finished products of TC11 titanium alloy, it can meet the requirements of aircraft structure temperature (below 300°C). Product Information Grade: GR1, GR2, GR4, GR5, GR7, GR12, GR23, TC11, TC21 Russian Grade: BT1-00,BT1-0,BT1-2, BT9, BT22 Standard: ASTM B348, AMS 4928, ASTM F67,ASTM F136 Diameter: 3-350mm Length: up to 6000mm Surface: Polished, Pickled Features: Polished surface with no defects, no cracks and no pitting. Chemical compositions(weight%,<=) Al Sn Mo Zr Si Fe C 5.8-7.0 -- 2.8-3.8 0.8-2.0 0.2-0.35 0.25 0.08 N H O Other(total) Ti 0.05 0.012 0.15 0.4 Remainder Physical properties(>=) Σb Tensile Strength (Mpa) σr0.2 Yield Strength (Mpa) δL0+50mm Elongation (%) ψ Reduction of area (%) 1030 900 10 30 Advantages 1. Price: As a leading manufacturer of titanium products, we have a history of more than 16 years and we know the market very well, so competitive prices can be offered. 2. Equipment: We have annealing furnaces, forging hammers, milling machines, straightening machines, shearing machines, trimming machines, punching machines, sandblasting machines etc. 3. Quality: Our titanium rods are sold to many countries. Our product is widely recognized. MTC, like EN10204.3.1, is available. Third-party test, such as TUV, SGS, BV etc., is also acceptable. 4. Shipment: Various modes of shipping. EXW, FOB, CIF etc. are all ok for us.
