Introduction
ASTM A285 /
A285M covers carbon steel plates intended for fusion-welded pressure vessels
requiring low to intermediate tensile strength. These plates are designed to
provide good weldability, formability, and dependable performance in pressure
vessel and boiler applications.
ASTM A285
carbon steel pressure vessel plates are widely used in industries where
moderate strength and reliable service under pressure are required.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of ASTM A285 /
A285M carbon steel pressure vessel plates, supplying high-quality plates for
boilers, storage tanks, and pressure vessel fabrication.
Applicable Standard
Standard
Specification: ASTM A285 / A285M
Organization: ASTM International
Title: Standard Specification for Pressure Vessel Plates, Carbon Steel, Low-
and Intermediate-Tensile Strength
This
specification covers carbon steel plates for fusion-welded pressure vessels
with low and intermediate tensile strength requirements.
Forms of Supply
ASTM A285
carbon steel plates are supplied in the following forms:
Hot rolled
plates
Cut-to-size plates
Flame cut plates
Profile cut plates
Supply
Condition
As-rolled
condition
Normalized condition (if required)
Surface
Finish
Mill finish
Shot blasted
Coated finish (if required)
Standard
Sizes
Thickness: 6
mm to 150 mm
Width: Up to 3000 mm
Length: Up to 12000 mm or as required
Grades Covered Under ASTM A285 / A285M
Grade A
Grade B
Grade C
These grades
provide varying tensile strengths suitable for different pressure vessel
applications.
|
Elements |
Grade A |
Grade B |
Grade C |
|
Carbon,
max |
0.17 |
0.22 |
0.28 |
|
Manganese,
max (Heat analysis) |
0.90 |
0.90 |
0.90 |
|
Manganese,
max (Product analysis) |
0.98 |
0.98 |
0.98 |
|
Phosphorus,
max |
0.025 |
0.025 |
0.025 |
|
Sulfur,
max |
0.025 |
0.025 |
0.025 |
Note: Applies to
both heat and product analyses.
Tensile Requirements
|
Property |
Grade A |
Grade B |
Grade C |
|
Tensile
Strength (ksi) |
45–65 |
50–70 |
55–75 |
|
Tensile
Strength (MPa) |
310–450 |
345–485 |
380–515 |
|
Yield
Strength, min (ksi) |
24 |
27 |
30 |
|
Yield
Strength, min (MPa) |
165 |
185 |
205 |
|
Elongation
in 8 in. [200 mm], % (min) |
27 |
25 |
23 |
|
Elongation
in 2 in. [50 mm], % (min) |
30 |
28 |
27 |
Key Features of ASTM A285 Carbon Steel Pressure Vessel
Plates
Excellent
weldability
Good formability for vessel fabrication
Reliable performance under moderate pressure
Cost-effective solution for boiler and tank manufacturing
Available in multiple grades for varied strength requirements
Suitable for low and intermediate tensile applications
Applications of ASTM A285 Carbon Steel Pressure Vessel
Plates
ASTM A285 plates are widely used in industries requiring dependable steel
plates for pressure-retaining applications.
Pressure
Vessels
• Welded pressure vessels
• Storage tanks
Boiler
Industry
• Boiler shells
• Steam tanks
Petrochemical
Industry
• Process vessels
• Low-pressure tanks
Industrial
Fabrication
• Structural tanks
• Fabricated vessel components
Heat Treatment
Plates are
generally supplied in as-rolled condition
Normalizing may be performed to improve toughness and strength
Heat treatment enhances uniformity and fabrication performance
Conclusion
ASTM A285 /
A285M carbon steel pressure vessel plates offer an economical and reliable
solution for boilers, tanks, and pressure vessel applications requiring low to
intermediate tensile strength. With good weldability and dependable mechanical
properties, these plates are ideal for fabrication in moderate pressure
environments.
Ladhani
Metal Corporation supplies ASTM A285 / A285M carbon steel pressure vessel
plates in various grades and sizes, ensuring high-quality products for pressure
vessels, boilers, and industrial fabrication applications.
