Name: Titanium Anodising Jigs
Availability: instock

Product Name: Titanium Rack Material: Gr1, Gr2 Application: Anodizing Size: Customized Surface: Bright Generally, titanium jigs/racks have a long life because they do not consume chemicals and they do not need to be stripped after anodizing. They can specially design all kinds of fingers, clips and other contact points and be sized to maximize the volume of parts. Titanium jigs can also be designed to keep parts superior to rinsing and drainage, and protect parts from damage during travel. Therefore, a well-designed shelf is an effective way to improve the processing capacity (i.e. better quality). The finishing cost is reduced by increasing the utilization rate of the tank and avoiding the stripping requirements. When designing the fast shelf and disassembly tools, the load is increased to the greatest extent, so as to produce faster turnover time. The problem is that these titanium racks for anodizing can be very expensive considering the cost of materials and the special cutting and welding processes used to build them. Generally speaking, the recovery period of titanium stent is about [500 uses]. The delivery time of titanium alloy rack is usually about 8 weeks after the design is completed, so the use of titanium rack also needs some planning. The design of titanium anodising jigs should consider the shape of the part, the nature of the plating solution, the production method, the distance and position between the anodes, and the number of workpieces, to ensure that the power lines of the parts in the bath are evenly distributed, the thickness of the coating is uniform, and the process requirements are met. The function of titanium anodising jigs is to suspend or fix various parts to connect them with the cathode. During anodizing and electroplating, they are connected with the anode to conduct current to the parts to achieve plating or other processing purposes. Titanium anodising jigs are of great significance for improving product quality, reducing manufacturing costs, reducing labor intensity and safe operation.

Titanium Jigs For Coating

Product Name: Titanium Jigs for coating Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished Titanium jigs for plating Any project to anodize requires a reliable hanger/jig/rack, first to prevent it from falling to the bottom of the anodizing tank, and second to allow the current to be safely transferred from the jig to the workpiece. Anodic oxidation clamps are usually made of aluminum or titanium. Aluminum fixtures must of course be anodized and must be chemically stripped. Continuous anodizing and stripping can result in short service life, so there is no need to strip titanium after the anodizing process. Item Name: titanium jig for coating Size:Customized size is welcomed Material: Titanium Gr1, Gr2 Application,Electroplating industry Surface:Sand Blasting, Acid Washing Parameter:Current density≤2000A/M2 Temperature:<65°C PH: 0.1~14 Max content of Fluoride ion is 200PPM Chemical composition (Wt%) ASTM No. Fe max O max N max C max H max Pd Al Bal Grade 1 0.2 0.18 0.03 0.1 0.015 - - Ti Grade 2 0.3 0.25 0.03 0.1 0.015 - - Ti Physical Properties (Min) ASTM Grade Alloy Composition Tensile Strength Yield Strength Elongation min % ksi Mpa ksi Mpa Grade 1 Unalloyed Ti ("Pure") 35A -CP1 35 240 25 170 30 Grade 2 Unalloyed Ti ("Pure") 50A -CP2 58 400 40 275 25

Pure Titanium Jigs For Electroplating

Product Name: Pure titanium jigs For Electroplating Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished Pure titanium jigs For Electroplating Titanium fixtures and racks are mainly used in electroplating, anodizing and other industries. Anodizing fixtures are usually made of aluminum or titanium. The aluminum fixture is anodized after being used for a period of time and must be chemically cleaned. Continuous anodizing and stripping lead to short service life. Therefore, the titanium that does not need to be stripped after anodizing is used. Titanium has been widely used in a large number of applications. Advantages of titanium jigs : ● titanium jigs, consistent from operation to operation. ● titanium fixtures and racks are not anodized like aluminum racks. Therefore, you can use your rectifier anodized parts instead of the rack. ● the high initial cost of titanium jig is offset by the advantages of titanium process savings, better consistency and longer service life. Product name titanium anodizing rack/titanium jigs for anodizing Material Titanium Gr1 Gr2 Technology Sand Blasting, Acid Washing Dimension & Shape Different dimension and shape is available,or according to customer's drawing Parameter Current density≤2000A/M2 Temperature<65°C PH 0.1~14 Max content of Fluoride ion is 200PPM Features Superior electric catalytic property Strong anti-corrosion property High current efficiency property Keep the operating voltage stably Decrease the wastage of additive Keep the plating solution stable Long lifetime Different complex geometry design Applications Ø Precious metal plating(Ag, Au, Rh, Pd) Ø Hard chrome plating(Cr6+) Ø Base metal plating(Cu, Zn, Ni) Ø Precious metal recovery, etc. Remarks Titanium anode also called MMO anode,DSA & Insoluble anode Cathode also be provided Packing Plywood case or carton, or according to customer’s demand

Anodic Titanium Jigs

Product Name: Anodic Titanium Jigs Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished Anodic Titanium Jigs Hanger/jig/rack, in electroplating and related operations, a frame for suspending a workpiece and directing an electric current to the workpiece. Hangers come in many forms, from general hangers for several common parts to hangers for large quantities of parts. For plating parts with complex geometry, some should be equipped with auxiliary anode, auxiliary cathode or shielding plate The basic principle of hanger design is: enough mechanical strength and good electrical conductivity, light weight, easy to unload, parts and hanger firmly contact. The titanium hanger has sufficient mechanical strength and good electrical conductivity Product Name:Anodic Titanium Jigs Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished Characteristics: 1. High density, heavy, high hardness and toughness; 2. Corrosion resistance in anodic treatment; 3. No insulation layer will be formed after anodic treatment.

Titanium Round Bar 25mm

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright

Titanium Anodizing Rack Jigs

Product Name: Titanium Anodizing Rack jigs Material: Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished Titanium Anodizing Rack jigs Titanium rack/jig, used for electroplating process, for electroplating products and introducing current into the product frame. Electroplating rack/jig can be divided into many types according to product shape, electroplating process requirements, electroplating process and equipment size. With years of experience and expertise, we are able to customize different style titanium racks to meet customer specific parts, while always providing fast turnaround.

Grade 4 Titanium Bar

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright Grade 4 titanium bar is stronger than grade 2 and 3. It can be cold formed, but is less ductile. It has excellent corrosion resistance in a variety of environments. Grade 4 titanium bars are commonly used in aerospace, industrial and medical applications where high strength is required.

Titanium Anodizing Jigs

Product Name: Titanium anodizing jigs Material: Gr1, Gr2 Application: Electroplating, anodizing etc. Size: Customized Surface: Polished What is a titanium anodizing jigs/titanium jig/titanium rack? Titanium installation in electroplating production is mainly conducted, supported and fixed parts, pendants and electrode connections, so that the current is more evenly transmitted to the parts for electroplating. In some cases, the uniform distribution of the coating can also be compensated by a suspension because the solution properties limit it. Item Anodizing Tianium jig/rack Size Customsed size Material Titanium Size(mm)in Bulk Stock 20/30/50 teeth Can be customized Grade Gr1 Gr2 Performance Corrosion-resisant Chemical composition (Wt%) ASTM No. Fe max O max N max C max H max Pd Al Bal Grade 1 0.2 0.18 0.03 0.1 0.015 - - Ti Grade 2 0.3 0.25 0.03 0.1 0.015 - - Ti Physical Properties (Min) of Titanium Anodizing Jigs ASTM Grade Alloy Composition Tensile Strength Yield Strength Elongation min % ksi Mpa ksi Mpa Grade 1 Unalloyed Ti ("Pure") 35A -CP1 35 240 25 170 30 Grade 2 Unalloyed Ti ("Pure") 50A -CP2 58 400 40 275 25

Titanium Elliptical Dish Tank Head

Product name: Titanium Elliptical Dish Tank Head Standard: ASME VIII-I, DIN28013 Material: GR1, GR2, GR7, GR12 Size: Customized Titanium Elliptical Dish Tank Head The Elliptical Dish Tank Head is the lid of the pressure vessel and the main bearing part of the pressure vessel. Its function is to seal. One is an upper and lower pressure vessel consisting of a tank, and the other end is a pipe, which does not extend forward, and is then welded to seal the pipe in the form of a header. The head of the product acts like a blind and a lid, but both can be removed. And the head can not be removed after welding. With support pressure vessels, pipes, flanges, elbows, tees, stone products. The quality of Elliptical Dish Tank Head /dish head is directly related to the long-term safe and reliable operation of pressure vessel. Diameter 300 mm to 2000 mm Shape Round Thickness 1 to 16 mm Process Industrial use Material grade CP4 - level; CP3 - secondary; Titanium contact international.like apply SSDS - level 3; CP1 - level 4; Seven; ; Grade 11 -CP ti-0.15pd; Grade 5 - Titanium 6Al-4V; Grade 6 -- Titanium 5Al-2.5Sn; Grade 9 - Titanium 3Al-2.5V; 12-0.8 Ni Ti - 0.3 - Mo -; Grade 19 - Titanium βC; Grade 23 - Titanium 6Al-4V ELI; 6, 6 v - 2 sn; 6 al zr - 2-2 sn - 4 mo; 6 al zr - 2 sn - 4-6 mo; Mo 8 al - 1-1 v. Fe 10 v - 2-3 al; 15 v - 3 cr - 3 sn - 3 al; Alpha alloy; Beta alloy; Alpha beta alloy Purpose Forging Features Solid construction Smooth Finish High quality Type of disk head/endcaps/head: Ellipsoidal head This is also known as a 2:1 oval head. This head shape is more economical because the height of the head is only a quarter of its diameter. Its radius varies between the major axis and the minor axis. Hemispherical head A sphere is the ideal shape for the head because the pressure in the container is evenly distributed over the surface of the head. The head radius (R) is equal to the radius of the cylindrical part of the container. Torispherical head These have a disc head with a fixed radius (CR), the size of which depends on the type of spherical head. The transition between the cylinder and the plate is called the knuckle. The steering knuckle is circular. Klopper head This is a spherical head. The radius of the plate is equal to the diameter of the cylinder to which it is attached. The radius of the knuckle is equal to one tenth of the diameter of the cylinder. Korbbogen head This is a hemispherical head, also known as a hemispherical head (DIN 28013). The radius of the disk is 80% of the diameter of the cylinder (CR=0.8 x D0.). The radius of the knuckle is (KR= 0.154x D0).
