Introduction JIS G 3114 specifies hot-rolled atmospheric corrosion resisting steel sheets and plates for welded structures. These weathering steels are designed to provide good strength, weldability and resistance to atmospheric corrosion, making them suitable for outdoor structural applications. JIS G 3114 steel sheets and plates are widely used for bridges, buildings, railway structures, infrastructure projects and other welded structures exposed to atmospheric conditions. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3114 steel sheets and plates, supplying the required grades, dimensions, thicknesses, surface finishes and delivery conditions as per customer requirements. Available Grades SMA400AP | SMA400AW | SMA400BP | SMA400BW | SMA400CP | SMA400CW | SMA490AP | SMA490AW | SMA490BP | SMA490BW | SMA490CP | SMA490CW | SMA570P | SMA570W Forms of Supply Steel Sheets | Steel Plates | Hot Rolled Sheets | Hot Rolled Plates | Steel Strips | Cut-to-Length Plates Material Type Weathering Steel | Atmospheric Corrosion Resisting Steel | Welded Structural Steel Chemical Composition SMA400AW: C 0.18% max. | Si 0.15–0.65% | Mn 1.25% max. | P 0.035% max. | S 0.035% max. | Cu 0.30–0.50% | Cr 0.45–0.75% | Ni 0.05–0.30% Mechanical Properties SMA400: Tensile strength 400–540 MPa SMA490: Tensile strength 490–610 MPa SMA570: Tensile strength 570 MPa class Surface Finish Hot Rolled | Mill Finish | Descaled | Pickled | Oiled | Cut Edge | Mill Edge Delivery Condition As Rolled | Normalized | Tempered | Quenched and Tempered | Thermomechanically Controlled Process | Cut-to-Length Key Features • Excellent atmospheric corrosion resistance • Good structural strength • Good weldability • Formation of a protective weathering layer • Suitable for outdoor structural applications • Reduced maintenance requirements in suitable environments • Available in different grades and thicknesses • Suitable for welded structural fabrication Applications • Bridges and bridge structures • Building and architectural structures • Railway structures • Outdoor structural frameworks • Industrial structures • Steel towers and supports • Infrastructure projects • Storage and transportation structures • Welded structural components • Heavy fabrication • General outdoor engineering applications Conclusion JIS G 3114 SMA400, SMA490 and SMA570 steel sheets and plates provide reliable weathering steel solutions for welded structures requiring strength, weldability and atmospheric corrosion resistance. To place an order or make an enquiry for JIS G 3114 steel sheets and plates, contact Ladhani Metal Corporation for your required grade, thickness, width, length, surface finish, delivery condition and quantity. #JISG3114 #JISG3114Steel #JISG3114SteelSheets #JISG3114SteelPlates #JISG3114Standard #JISG3114CortenSteel #WeatheringSteel #WeatheringSteelPlates #AtmosphericCorrosionResistantSteel #CorrosionResistantSteel #HotRolledSteel #HotRolledSteelSheets #HotRolledSteelPlates #WeldableSteel #StructuralSteel #SteelSheets #SteelPlates #SteelPlateManufacturer #SteelPlateSupplier #SteelPlateExporter #SteelManufacturer #SteelSupplier #SteelExporter #SteelStockist #SteelDistributor #IndustrialSteel #EngineeringSteel #JISStandards #JapaneseSteelStandards #LadhaniMetalCorporation #Mumbai #Delhi #Chennai #Kolkata #Bengaluru #Hyderabad #Ahmedabad #Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore #Srinagar #Aurangabad #Dhanbad #Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah #Jabalpur

Introduction JIS G 3106 specifies rolled steels for welded structures and covers steel plates, sheets, strips, sections and flats used for welded structural applications. The standard includes grades designed to provide suitable strength, weldability and toughness for demanding structural applications. JIS G 3106 rolled steel sheets are widely used for bridges, ships, railway structures, storage tanks, containers, construction equipment and general welded structures. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3106 rolled steel sheets, supplying the required grades, dimensions, thicknesses, surface finishes and delivery conditions as per customer requirements. Available Grades SM400A | SM400B | SM400C | SM490A | SM490B | SM490C | SM490YA | SM490YB | SM520B | SM520C | SM570 Forms of Supply Rolled steel sheets | Hot rolled sheets | Steel plates | Steel strips | Cut-to-length sheets | Structural sections | Flats Material Type Welded Structural Steel | Carbon Steel | Hot-Rolled Structural Steel Chemical Composition SM490B: C 0.18% max. | Si 0.55% max. | Mn 1.65% max. | P 0.035% max. | S 0.035% max. Mechanical Properties SM400A/B/C: Tensile strength 400–510 MPa SM490A/B/C: Tensile strength 490–610 MPa SM490YA/YB: Tensile strength 490–610 MPa SM520B/C: Tensile strength 520–640 MPa SM570: Tensile strength 570–720 MPa Surface Finish Hot Rolled | Mill Finish | Descaled | Pickled | Oiled | Cut Edge | Mill Edge Delivery Condition As Rolled | Normalized | Controlled Delivery | Cut-to-Length | Heat Treated as Required Key Features • Excellent weldability • Good structural strength • Suitable for welded structural fabrication • Good toughness and impact resistance • Available in different grades and thicknesses • Suitable for heavy structural applications • Supplied with mill test certificates and inspection documentation Applications • Bridges and bridge structures • Shipbuilding and marine structures • Railway and rolling stock structures • Petroleum storage tanks • Industrial containers • Structural frames and supports • Heavy fabrication • Construction and engineering structures • Welded machinery and equipment • General welded structural applications Conclusion JIS G 3106 SM400, SM490, SM520 and SM570 rolled steel sheets provide reliable welded structural steel solutions for demanding fabrication and engineering applications. Ladhani Metal Corporation can supply these materials according to the required grade, thickness, width, length, surface finish, delivery condition and quantity. To place an order or make an enquiry for JIS G 3106 rolled steel sheets, contact Ladhani Metal Corporation. #JISG3106 #JISG3106Steel #JISG3106RolledSteel #JISG3106Standard #JISG3106Sheets #RolledSteelSheets #StructuralSteel #WeldableSteel #SteelSheets #SteelPlates #CarbonSteel #StructuralSteelPlates #MildSteel #MSSheets #MSPlates #SteelSheetManufacturer #SteelSheetSupplier #SteelSheetExporter #SteelManufacturer #SteelSupplier #SteelExporter #SteelStockist #SteelDistributor #IndustrialSteel #EngineeringSteel #SteelProducts #JISStandards #JapaneseSteelStandards #IndustrialMaterials #Mumbai #Delhi #Chennai #Kolkata #Bengaluru #Hyderabad #Ahmedabad #Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore #Srinagar #Aurangabad #Dhanbad #Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah #Jabalpur #Gwalior #Vijayawada #Jodhpur #Raipur #Kota #Guwahati #Chandigarh #Solapur #Hubli #Mysuru #Tiruchirappalli

Introduction JIS G 3103 specifies hot-rolled steel plates of carbon steel and molybdenum alloy steel for boilers and pressure vessels. The standard covers five grades: SB410, SB450, SB480, SB450M and SB480M. JIS G 3103 steel plates are designed for boiler, pressure vessel and high-temperature service applications, offering suitable strength and performance under elevated-temperature conditions. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3103 steel plates, supplying the required grades, thicknesses, dimensions, surface finishes and delivery conditions as per customer requirements. Available Grades SB410 | SB450 | SB480 | SB450M | SB480M Forms of Supply Steel Plates | Hot Rolled Plates | Boiler Plates | Pressure Vessel Plates | Cut-to-Length Plates Material Type Carbon Steel | Molybdenum Alloy Steel | Boiler & Pressure Vessel Steel Chemical Composition SB480: C 0.40% max. | Si 0.30% max. | Mn 1.30% max. | P 0.030% max. | S 0.030% max. | Mo 0.12% max. Mechanical Properties SB410: Yield strength 225 MPa min. | Tensile strength 410–550 MPa SB450: Yield strength 245 MPa min. | Tensile strength 450–590 MPa SB480: Yield strength 265 MPa min. | Tensile strength 480–620 MPa SB450M: Yield strength 255 MPa min. | Tensile strength 450–590 MPa SB480M: Yield strength 275 MPa min. | Tensile strength 480–620 MPa Surface Finish Hot Rolled | Mill Finish | Descaled | Pickled | Oiled | Cut Edge | Mill Edge Delivery Condition As Rolled | Normalized | Stress Relief Annealed | Heat Treated as Required | Cut-to-Length Key Features • Suitable for boilers and pressure vessels • Available in carbon steel and molybdenum alloy steel grades • Good strength for pressure-containing applications • Suitable for elevated-temperature service • Good weldability and fabrication characteristics • Available in different thicknesses and dimensions • Supplied with required inspection and mill test certificates Applications • Boilers and boiler components • Pressure vessels • Steam drums • Heat exchangers • Industrial heating equipment • Power generation equipment • High-temperature process equipment • Chemical processing equipment • Petrochemical equipment • Fabricated pressure-containing structures Conclusion JIS G 3103 SB410, SB450, SB480, SB450M and SB480M steel plates provide reliable carbon steel and molybdenum alloy steel solutions for boiler and pressure vessel applications. To place an order or make an enquiry for JIS G 3103 steel plates, contact Ladhani Metal Corporation for your required grade, thickness, width, length, surface finish, delivery condition and quantity.
