Introduction JIS G 3106 specifies rolled steels for welded structures and covers steel plates, sheets, strips, sections and flats used for welded structural applications. The standard includes grades designed to provide suitable strength, weldability and toughness for demanding structural applications. JIS G 3106 rolled steel sheets are widely used for bridges, ships, railway structures, storage tanks, containers, construction equipment and general welded structures. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3106 rolled steel sheets, supplying the required grades, dimensions, thicknesses, surface finishes and delivery conditions as per customer requirements. Available Grades SM400A | SM400B | SM400C | SM490A | SM490B | SM490C | SM490YA | SM490YB | SM520B | SM520C | SM570 Forms of Supply Rolled steel sheets | Hot rolled sheets | Steel plates | Steel strips | Cut-to-length sheets | Structural sections | Flats Material Type Welded Structural Steel | Carbon Steel | Hot-Rolled Structural Steel Chemical Composition SM490B: C 0.18% max. | Si 0.55% max. | Mn 1.65% max. | P 0.035% max. | S 0.035% max. Mechanical Properties SM400A/B/C: Tensile strength 400–510 MPa SM490A/B/C: Tensile strength 490–610 MPa SM490YA/YB: Tensile strength 490–610 MPa SM520B/C: Tensile strength 520–640 MPa SM570: Tensile strength 570–720 MPa Surface Finish Hot Rolled | Mill Finish | Descaled | Pickled | Oiled | Cut Edge | Mill Edge Delivery Condition As Rolled | Normalized | Controlled Delivery | Cut-to-Length | Heat Treated as Required Key Features • Excellent weldability • Good structural strength • Suitable for welded structural fabrication • Good toughness and impact resistance • Available in different grades and thicknesses • Suitable for heavy structural applications • Supplied with mill test certificates and inspection documentation Applications • Bridges and bridge structures • Shipbuilding and marine structures • Railway and rolling stock structures • Petroleum storage tanks • Industrial containers • Structural frames and supports • Heavy fabrication • Construction and engineering structures • Welded machinery and equipment • General welded structural applications Conclusion JIS G 3106 SM400, SM490, SM520 and SM570 rolled steel sheets provide reliable welded structural steel solutions for demanding fabrication and engineering applications. Ladhani Metal Corporation can supply these materials according to the required grade, thickness, width, length, surface finish, delivery condition and quantity. To place an order or make an enquiry for JIS G 3106 rolled steel sheets, contact Ladhani Metal Corporation. #JISG3106 #JISG3106Steel #JISG3106RolledSteel #JISG3106Standard #JISG3106Sheets #RolledSteelSheets #StructuralSteel #WeldableSteel #SteelSheets #SteelPlates #CarbonSteel #StructuralSteelPlates #MildSteel #MSSheets #MSPlates #SteelSheetManufacturer #SteelSheetSupplier #SteelSheetExporter #SteelManufacturer #SteelSupplier #SteelExporter #SteelStockist #SteelDistributor #IndustrialSteel #EngineeringSteel #SteelProducts #JISStandards #JapaneseSteelStandards #IndustrialMaterials #Mumbai #Delhi #Chennai #Kolkata #Bengaluru #Hyderabad #Ahmedabad #Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore #Srinagar #Aurangabad #Dhanbad #Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah #Jabalpur #Gwalior #Vijayawada #Jodhpur #Raipur #Kota #Guwahati #Chandigarh #Solapur #Hubli #Mysuru #Tiruchirappalli

Introduction JIS G 3103 specifies hot-rolled steel plates of carbon steel and molybdenum alloy steel for boilers and pressure vessels. The standard covers five grades: SB410, SB450, SB480, SB450M and SB480M. JIS G 3103 steel plates are designed for boiler, pressure vessel and high-temperature service applications, offering suitable strength and performance under elevated-temperature conditions. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3103 steel plates, supplying the required grades, thicknesses, dimensions, surface finishes and delivery conditions as per customer requirements. Available Grades SB410 | SB450 | SB480 | SB450M | SB480M Forms of Supply Steel Plates | Hot Rolled Plates | Boiler Plates | Pressure Vessel Plates | Cut-to-Length Plates Material Type Carbon Steel | Molybdenum Alloy Steel | Boiler & Pressure Vessel Steel Chemical Composition SB480: C 0.40% max. | Si 0.30% max. | Mn 1.30% max. | P 0.030% max. | S 0.030% max. | Mo 0.12% max. Mechanical Properties SB410: Yield strength 225 MPa min. | Tensile strength 410–550 MPa SB450: Yield strength 245 MPa min. | Tensile strength 450–590 MPa SB480: Yield strength 265 MPa min. | Tensile strength 480–620 MPa SB450M: Yield strength 255 MPa min. | Tensile strength 450–590 MPa SB480M: Yield strength 275 MPa min. | Tensile strength 480–620 MPa Surface Finish Hot Rolled | Mill Finish | Descaled | Pickled | Oiled | Cut Edge | Mill Edge Delivery Condition As Rolled | Normalized | Stress Relief Annealed | Heat Treated as Required | Cut-to-Length Key Features • Suitable for boilers and pressure vessels • Available in carbon steel and molybdenum alloy steel grades • Good strength for pressure-containing applications • Suitable for elevated-temperature service • Good weldability and fabrication characteristics • Available in different thicknesses and dimensions • Supplied with required inspection and mill test certificates Applications • Boilers and boiler components • Pressure vessels • Steam drums • Heat exchangers • Industrial heating equipment • Power generation equipment • High-temperature process equipment • Chemical processing equipment • Petrochemical equipment • Fabricated pressure-containing structures Conclusion JIS G 3103 SB410, SB450, SB480, SB450M and SB480M steel plates provide reliable carbon steel and molybdenum alloy steel solutions for boiler and pressure vessel applications. To place an order or make an enquiry for JIS G 3103 steel plates, contact Ladhani Metal Corporation for your required grade, thickness, width, length, surface finish, delivery condition and quantity.

Introduction JIS G 3101 specifies rolled steels for general structure and covers mild steel / carbon steel grades used for general structural applications. The standard includes SS330, SS400, SS490 and SS540 grades with specified strength, elongation and bendability requirements. JIS G 3101 rolled steel sheets are widely used for construction, structural fabrication, civil engineering, machinery and general engineering applications. Ladhani Metal Corporation is a manufacturer, supplier, and exporter of JIS G 3101 rolled steel sheets, supplying the required grades, dimensions, thicknesses, surface finishes and delivery conditions as per customer requirements. Available Grades SS330 | SS400 | SS490 | SS540 Forms of Supply Rolled steel sheets | Hot rolled sheets | Steel plates | Steel strips | Cut-to-length sheets | Flats | Sections Material Type Mild Steel (MS) | Carbon Steel (CS) | General Structural Steel Chemical Composition SS330: P 0.050% max. | S 0.050% max. SS400: P 0.050% max. | S 0.050% max. SS490: P 0.050% max. | S 0.050% max. SS540: C 0.30% max. | Mn 1.60% max. | P 0.040% max. | S 0.040% maX Mechanical Properties SS330: Yield strength 205 MPa min. | Tensile strength 330–430 MPa SS400: Yield strength 245 MPa min. | Tensile strength 400–510 MPa SS490: Yield strength 285 MPa min. | Tensile strength 490–610 MPa SS540: Yield strength 400 MPa min. | Tensile strength 540 MPa min. Surface Finish Hot rolled | Mill finish | Descaled | Pickled | Oiled | Cut-edge | Mill-edge Delivery Condition As rolled | Cut-to-length | Straightened | Customized delivery condition as per requirements Key Features • Good structural strength • Suitable for general fabrication • Good formability and bendability • Suitable for welding and fabrication depending on grade and thickness • Available in different thicknesses and dimensions • Suitable for general engineering requirements • Supplied with required inspection and mill test documentation Applications • Construction and structural fabrication • Civil engineering projects • Bridges and structural components • Building frames and supports • Foundation bolts and structural fasteners • Industrial machinery and equipment • Platforms, brackets and supports • General machine parts • Transportation and fabricated steel structures • General engineering applications Conclusion JIS G 3101 SS330, SS400, SS490 and SS540 rolled steel sheets provide reliable mild steel / carbon steel solutions for general structural applications. Ladhani Metal Corporation can supply these materials according to the required grade, thickness, width, length, surface finish and quantity. To place an order or make an enquiry for JIS G 3101 rolled steel sheets, contact Ladhani Metal Corporation. #JISG3101 #JISG3101Steel #JISG3101Standard #JISG3101Plates #JISG3101Bars #JISG3101StructuralSteel #StructuralSteel #RolledSteel #MildSteel #CarbonSteel #MSPlates #MSBars #SteelPlates #SteelBars #StructuralSteelPlates #StructuralSteelBars #SteelManufacturer #SteelSupplier #SteelExporter #SteelStockist #SteelDistributor #IndustrialSteel #EngineeringSteel #CarbonSteelProducts #MildSteelProducts #SteelProducts #JISStandards #JapaneseSteelStandards #IndustrialMaterials #LadhaniMetalCorporation #Mumbai #Delhi #Chennai #Kolkata #Bengaluru #Hyderabad #Ahmedabad #Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore #Srinagar #Aurangabad #Dhanbad #Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah #Jabalpur #Gwalior #Vijayawada #Jodhpur #Raipur #Kota #Guwahati #Chandigarh #Solapur #Hubli #Mysuru #Tiruchirappalli #Bareilly
