Introduction
EN 10268
is a European standard covering cold rolled flat steel products with high yield
strength for cold forming applications. These steels are produced using
controlled rolling and micro-alloying techniques to achieve an excellent
combination of strength, formability, weldability, and dimensional accuracy.
EN 10268
steel sheets, plates, coils, and strips are extensively used in automotive
manufacturing, transportation equipment, construction machinery, agricultural
equipment, and industrial fabrication. Their high yield strength enables
manufacturers to reduce component weight while maintaining structural
performance and durability.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of EN 10268 steel
sheets, plates, coils, and strips, supplying premium-quality high-strength
steel products for engineering and fabrication applications worldwide.
Applicable Standard
Standard
Specification: EN 10268
Organization:
European Committee for Standardization (CEN)
Title:
Cold Rolled Steel Flat Products with High Yield Strength for Cold Forming –
Technical Delivery Conditions
This
standard specifies requirements for cold rolled flat steel products with high
yield strength intended for cold forming operations.
Forms of Supply
EN 10268
steel products are supplied in the following forms:
- Steel sheets
- Steel plates
- Steel coils
- Steel strips
- Cold rolled sheets
- Cold rolled plates
- Slit coils
- Cut-to-length sheets
- Precision cut plates
- Flat steel products
- Customized blanks
- Profile cut components
- Fabricated steel parts
Grades Covered Under EN 10268
- HC260LA
- HC300LA
- HC340LA
- HC380LA
- HC420LA
- HC460LA
- HC500LA
- HC550LA
Supply Condition
- Cold rolled
- Skin passed
- Temper rolled
- Oiled condition
- Dry condition
- Cut-to-length condition
Surface Finish
- Cold rolled finish
- Bright finish
- Smooth finish
- Oiled finish
- Skin passed finish
- Mill finish
Standard Sizes
Thickness:
0.40 mm to 4.00 mm
Width:
600 mm to 2000 mm
Length:
Up to 6000 mm
Coil
Weight: Up to 30 metric tons
Custom
dimensions are available according to customer requirements.
Chemical Composition of EN 10268 Grades (%)
|
Steel Name |
C Max (%) |
Si Max (%) |
Mn Max (%) |
P Max (%) |
S Max (%) |
Al Min (%) |
Ti Max (%) |
Nb Max (%) |
|
HC180Y |
0.01 |
0.3 |
0.7 |
0.06 |
0.025 |
0.01 |
0.12 |
0.09 |
|
HC180B |
0.06 |
0.5 |
0.7 |
0.06 |
0.030 |
0.015 |
— |
— |
|
HC220Y |
0.01 |
0.3 |
0.9 |
0.08 |
0.025 |
0.01 |
0.12 |
0.09 |
|
HC220I |
0.07 |
0.5 |
0.6 |
0.05 |
0.025 |
0.015 |
0.05 |
— |
|
HC220B |
0.08 |
0.5 |
0.7 |
0.085 |
0.030 |
0.015 |
— |
— |
|
HC260Y |
0.01 |
0.3 |
1.6 |
0.10 |
0.025 |
0.01 |
0.12 |
0.09 |
|
HC260I |
0.07 |
0.5 |
1.2 |
0.05 |
0.025 |
0.015 |
0.05 |
— |
|
HC260B |
0.10 |
0.5 |
1.0 |
0.10 |
0.030 |
0.015 |
— |
— |
|
HC260LA |
0.10 |
0.5 |
1.0 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC300I |
0.08 |
0.5 |
0.7 |
0.08 |
0.025 |
0.015 |
0.05 |
— |
|
HC300B |
0.10 |
0.5 |
1.0 |
0.12 |
0.030 |
0.015 |
— |
— |
|
HC300LA |
0.12 |
0.5 |
1.4 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC340LA |
0.12 |
0.5 |
1.5 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC380LA |
0.12 |
0.5 |
1.6 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC420LA |
0.14 |
0.5 |
1.6 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC460LA |
0.14 |
0.6 |
1.8 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
|
HC500LA |
0.14 |
0.6 |
1.8 |
0.030 |
0.025 |
0.015 |
0.15 |
0.09 |
Notes
a.
These additional elements may be used individually or in combination where they
appear in the definition of the steel within the composition limits indicated.
Vanadium and boron may also be added. However, the sum of the contents of these
four prescribed elements shall not exceed 0.22%.
b. For all interstitial free (Y)
grades, Nb may be added alternatively or in combination with Ti. For all grades
containing "I" in the designation, Ti can be substituted by Nb or B.
Mechanical
Properties of EN 10268 Steel
|
Grade |
Minimum Yield
Strength (MPa) |
Tensile Strength
(MPa) |
Minimum
Elongation (%) |
|
HC260LA |
260 |
350 – 430 |
27 |
|
HC300LA |
300 |
380 – 480 |
25 |
|
HC340LA |
340 |
410 – 510 |
23 |
|
HC380LA |
380 |
440 – 560 |
21 |
|
HC420LA |
420 |
480 – 620 |
19 |
|
HC460LA |
460 |
520 – 670 |
17 |
|
HC500LA |
500 |
550 – 720 |
16 |
|
HC550LA |
550 |
600 – 760 |
14 |
Mechanical
properties may vary depending on thickness and processing conditions.
Key Features of EN 10268 Sheets, Plates, Coils and Strips
- High yield strength
- Excellent cold formability
- Superior weldability
- Good dimensional accuracy
- Excellent surface quality
- Weight reduction capability
- Consistent mechanical properties
- Improved structural performance
- Suitable for automated
manufacturing
- Excellent fatigue resistance
Applications of EN 10268 Steel Products
Automotive Industry
- Chassis components
- Reinforcement parts
- Structural members
- Safety components
- Automotive frames
Transportation Industry
- Railway equipment
- Commercial vehicles
- Truck components
- Trailer structures
Construction Industry
- Structural sections
- Building reinforcements
- Engineering structures
- Load-bearing components
Agricultural Equipment
- Machinery frames
- Equipment structures
- Agricultural implements
- Heavy-duty components
Industrial Manufacturing
- Fabricated assemblies
- Machine structures
- Industrial equipment
- Material handling systems
General Engineering Applications
- Cold formed sections
- Structural fabrications
- Engineering components
- Precision fabricated products
Fabrication and Forming
EN 10268
steels are specifically designed for cold forming applications.
- Suitable for bending operations
- Excellent stamping performance
- Good roll-forming characteristics
- Suitable for profiling operations
- Excellent welding properties
- Good punching and cutting
performance
- High productivity during
fabrication
These
steels allow manufacturers to achieve complex component geometries while
maintaining high structural strength.
Heat Treatment
EN 10268
products are generally supplied in the cold rolled condition.
- Mechanical properties are achieved
through controlled rolling and micro-alloying
- Heat treatment is generally not
required before fabrication
- Suitable for stress relieving if
required
- Excellent stability during forming
operations
Advantages of EN 10268 Steel Products
- High strength-to-weight ratio
- Reduced material thickness
requirements
- Excellent manufacturing efficiency
- Improved structural performance
- Lower fabrication costs
- Excellent weldability
- Reliable quality consistency
- Suitable for lightweight design
concepts
- Enhanced durability and service
life
- Cost-effective engineering solution
Conclusion
EN 10268
HC260LA, HC300LA, HC340LA, HC380LA, HC420LA, HC460LA, HC500LA, and HC550LA
steel sheets, plates, coils, and strips are premium cold rolled high-strength
steels developed for cold forming and structural applications. Their
combination of high yield strength, excellent formability, superior
weldability, and lightweight performance makes them ideal for automotive,
transportation, construction, agricultural, and industrial manufacturing
sectors.
Ladhani Metal Corporation
supplies EN 10268 steel sheets, plates, coils, and strips in various grades,
thicknesses, widths, and customized dimensions, providing reliable material
solutions for high-strength engineering applications worldwide.
