Ladhani Metal Corporation
Dished Heads
DIN- ASME- STANDARD
Standard
Dimension:
Diameter (OD):
60,3 - 13.500 mm
Wall thickness (s):
3 – 250 mm
Typical forms: | |
- Torispherical head DIN 28011 | |
- Semi ellipsoidal head DIN28013 | |
- Ellipsoidal heads | |
- Hemispherical heads | |
- Standard/Flat dished heads | |
- Flat heads | |
- Convex discs | |
- Plate type heads | |
- Diffuser heads | |
| |
| |
| |
| |
| |
MATERIAL :
Carbon steel
P265-GH, 16Mo3, 15NiCuMoNb5
CrMo(V) Alloy steel
10CrMo9-10 , 13CrMo4-5
ASME SA 387 Gr.11, Gr.12, Gr.91
Carbon steel
P355-GH, -NH, -NL1, -NL2 ASME SA 516 Gr.60 , Gr.70
Stainless steel
1.4301 / ASME SA240- 304
1.4307 / ASME SA240- 304L
1.4404 / ASME SA240- 316, 316L
1.4541 / ASME SA240- 321, 321H
1.4571 / ASME SA240- 316Ti
1.4539 / ASME SA240- 904 L
Duplex and Super Duplex
1.4462 / ASTM Duplex 2205
1.4501 / ASTM SuperDuplexCr25
Nickel alloys
Alloy -20, -59, -200 MONEL -400 INCONEL -600, -601, -625 INCOLOY -800, -825
Copper, Titanium, Aluminium cadded material combinations
Test method:
Impact -Test at room temperature or low temperature acc. to DIN EN 10045-2 Tensile test acc to DIN EN 10002-1 , ISO 6892-1 , ASTM A 370
Hot tensile test acc to DIN EN 10002-5 until 900°C Hardness Test acc. to Brinell and DIN EN ISO 6506-1
Testing of intercrystalline corrosion acc to ISO 3651-2 (A) , ASTM A 262 Pract. E
X – Ray -Examination acc. to EN 1435 , ISO 5817 , ASME V Art.2 , VIII Div.1 § UW -51 UT - Ultrasonic testing acc. to EN 10160 , EN 10307 , ASME SA-578 , ASME SA-435 PT - Penetrant testing acc. to EN 571 , ASME V Art.6 , ASME VIII Div.1 App.8 MT- Magnetic particle testing acc. to EN 1291 , ASME V Art.7 , ASMEVIII Div.1 App.6
Design Code:
AD-2000 , BS PD 5500 , CODAP, EN 13445 + PED 97/23/EC ASME VIII, Div. 1 und Div. 2 , U-Stamp, U2-Stamp Authorization
Certificate:
Certificate acc. to EN 10204 - 3.1 and 3.2 from independent organization - Lloyd’s Reg. of Shipping ( LRS )
EN_29/v04 - TÜV , - DNV , - GL
