Introduction
ASTM A358 /
A358M covers electric-fusion-welded austenitic chromium-nickel stainless steel
pipes intended for high-temperature and corrosive service applications. These
pipes are manufactured using filler metal and are designed to provide excellent
corrosion resistance, strength, and reliability under demanding operating conditions.
ASTM A358
stainless steel pipes are widely used in industries requiring large diameter
welded pipes capable of handling high pressure and elevated temperatures.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of ASTM A358 /
A358M stainless steel pipes, supplying high-quality electric-fusion-welded
pipes for critical industrial applications.
Applicable Standard
Standard
Specification: ASTM A358 / A358M
Organization: ASTM International
Title: Standard Specification for Electric-Fusion-Welded Austenitic
Chromium-Nickel Alloy Steel Pipe for High-Temperature Service
This
specification covers electric-fusion-welded stainless steel pipes intended for
corrosive and high-temperature environments.
Forms of Supply
ASTM A358
stainless steel pipes are supplied in the following forms:
Electric-fusion-welded
pipes
Large diameter welded pipes
Straight length pipes
Cut-to-length pipes
Supply
Condition
Solution
annealed
Heat-treated condition
Pickled and passivated
Surface
Finish
Mill finish
Pickled finish
Polished finish (if required)
Standard
Sizes
Outside
Diameter: 219 mm to 3000 mm
Wall Thickness: 3 mm to 50 mm
Length: Up to 12 meters or as required
Grades Covered Under ASTM A358 / A358M
TP304L
TP316L
TP321
TP347
These grades
are austenitic stainless steels offering excellent corrosion resistance and
high-temperature strength.
Chemical Composition of ASTM A358 Stainless Steel
Pipes (%)
|
Grade |
Carbon |
Sulfur |
Manganese |
Chromium |
Phosphorus |
Silicon |
Molybdenum |
Nickel |
Titanium |
Niobium |
Nitrogen |
|
TP304 |
0.08 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
— |
8.0–11.0 |
— |
— |
— |
|
TP304L |
0.035 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
— |
8.0–13.0 |
— |
— |
— |
|
TP304H |
0.04–0.10 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
— |
8.0–11.0 |
— |
— |
— |
|
TP304N |
0.08 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
— |
8.0–18.0 |
— |
— |
0.10–0.16 |
|
TP304LN |
0.035 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
— |
8.0–12.0 |
— |
— |
0.10–0.16 |
|
TP309S |
0.08 |
0.030 |
2.0 |
22.0–24.0 |
0.045 |
1.0 |
0.75 |
12.0–15.0 |
— |
— |
— |
|
TP309H |
0.04–0.10 |
0.030 |
2.0 |
22.0–24.0 |
0.045 |
1.0 |
— |
12.0–15.0 |
— |
— |
— |
|
TP309Cb |
0.08 |
0.030 |
2.0 |
22.0–24.0 |
0.045 |
1.0 |
0.75 |
12.0–16.0 |
— |
10×C min,
1.10 max |
— |
|
TP309HCb |
0.04–0.10 |
0.030 |
2.0 |
22.0–24.0 |
0.045 |
1.0 |
0.75 |
12.0–16.0 |
— |
10×C min,
1.10 max |
— |
|
TP310S |
0.08 |
0.030 |
2.0 |
24.0–26.0 |
0.045 |
1.0 |
0.75 |
19.0–22.0 |
— |
— |
— |
|
TP310H |
0.04–0.10 |
0.030 |
2.0 |
24.0–26.0 |
0.045 |
1.0 |
— |
19.0–22.0 |
— |
— |
— |
|
TP310Cb |
0.08 |
0.030 |
2.0 |
24.0–26.0 |
0.045 |
1.0 |
0.75 |
19.0–22.0 |
— |
10×C min,
1.10 max |
— |
|
TP310HCb |
0.04–0.10 |
0.030 |
2.0 |
24.0–26.0 |
0.045 |
1.0 |
0.75 |
19.0–22.0 |
— |
10×C min,
1.10 max |
— |
|
TP316 |
0.08 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
1.0 |
2.0–3.0 |
11.0–14.0 |
— |
— |
— |
|
TP316L |
0.035 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
1.0 |
2.0–3.0 |
10.0–14.0 |
— |
— |
— |
|
TP316H |
0.04–0.10 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
1.0 |
2.0–3.0 |
11.0–14.0 |
— |
— |
— |
|
TP316Ti |
0.08 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
0.75 |
2.0–3.0 |
10.0–14.0 |
5×(C−N)–0.70 |
— |
0.10 |
|
TP316N |
0.08 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
1.0 |
2.0–3.0 |
10.0–14.0 |
— |
— |
0.10–0.16 |
|
TP316LN |
0.035 |
0.030 |
2.0 |
16.0–18.0 |
0.045 |
1.0 |
2.0–3.0 |
11.0–14.0 |
— |
— |
0.10–0.16 |
|
TP317 |
0.08 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
3.0–4.0 |
10.0–14.0 |
— |
— |
— |
|
TP317L |
0.035 |
0.030 |
2.0 |
18.0–20.0 |
0.045 |
1.0 |
3.0–4.0 |
11.0–15.0 |
— |
— |
— |
|
TP321 |
0.08 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–12.0 |
— |
— |
0.10 |
|
TP321H |
0.04–0.10 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–12.0 |
— |
— |
0.10 |
|
TP347 |
0.08 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–13.0 |
— |
— |
— |
|
TP347H |
0.04–0.10 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–13.0 |
— |
— |
— |
|
TP347LN |
0.05–0.20 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–13.0 |
— |
0.20–50.0 |
0.06–0.10 |
|
TP348 |
0.08 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–13.0 |
— |
— |
— |
|
TP348H |
0.04–0.10 |
0.030 |
2.0 |
17.0–19.0 |
0.045 |
1.0 |
— |
9.0–13.0 |
— |
— |
— |
Key Features of ASTM A358 Stainless Steel Pipes
Excellent
corrosion resistance
Suitable for high-temperature service
High strength and durability
Reliable welded construction
Good oxidation resistance
Available in large diameters
Long service life in aggressive environments
Applications of ASTM A358 Stainless Steel Pipes
ASTM A358
pipes are widely used in industries requiring corrosion resistance and
high-temperature performance.
Oil &
Gas Industry
• Process pipelines
• Refinery piping systems
Chemical
& Petrochemical Industry
• Corrosive fluid transportation
• Process equipment piping
Power Plants
• High-temperature piping
• Steam systems
Industrial
Applications
• Heat exchanger piping
• Pressure piping systems
Heat Treatment
Pipes are
solution annealed after welding
Heat treatment improves corrosion resistance and ductility
Ensures uniform microstructure and performance
Conclusion
ASTM A358 /
A358M stainless steel pipes provide a reliable solution for high-temperature
and corrosive applications. With excellent weld integrity, corrosion
resistance, and availability in large diameters, these pipes are ideal for
demanding industrial environments.
Ladhani
Metal Corporation supplies ASTM A358 / A358M stainless steel pipes in various
grades and sizes, ensuring high-quality products for oil & gas,
petrochemical, and power generation industries.
