Introduction
ASTM A213 /
A213M covers seamless ferritic and austenitic alloy steel tubes intended for
boilers, superheaters, and heat exchangers. These tubes are designed for
high-temperature service and provide excellent strength, corrosion resistance,
and long-term durability under pressure.
ASTM A213
tubes are widely used in power plants, refineries, and industrial heating
systems where performance at elevated temperatures and resistance to oxidation
are critical.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of ASTM A213 /
A213M seamless alloy steel tubes, supplying high-quality tubes for critical
boiler and heat exchanger applications.
Applicable Standard
Standard
Specification: ASTM A213 / A213M
Organization: ASTM International
Title: Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel
Boiler, Superheater, and Heat Exchanger Tubes
This
specification covers seamless alloy steel tubes for high-temperature and
pressure service.
Forms of Supply
ASTM A213
alloy steel tubes are supplied in the following forms:
Seamless
tubes
Hot finished tubes
Cold drawn tubes
U-bend tubes
Cut-to-length tubes
Supply
Condition
Annealed
condition
Normalized condition
Heat-treated condition
Surface
Finish
Mill finish
Pickled
Bright annealed
Standard
Sizes
Outside
Diameter: 6 mm to 127 mm
Wall Thickness: 0.5 mm to 12.7 mm
Length: Up to 12 meters or as required
Grades Covered Under ASTM A213 / A213M
Ferritic
Alloy Steel Grades:
T5
T9
T11
T22
Austenitic
Stainless Steel Grades:
TP304
TP304L
TP316
TP316L
TP321
TP347
These grades
are designed to provide a combination of high-temperature strength, oxidation
resistance, and corrosion resistance.
Chemical Composition
Limits (%) – Low Alloy Steel
|
Grade |
Carbon
(C) |
Manganese
(Mn) |
Phosphorus
(P) |
Sulfur
(S) |
Silicon
(Si) |
Nickel
(Ni) |
Chromium
(Cr) |
Molybdenum
(Mo) |
Vanadium
(V) |
Boron
(B) |
Niobium
(Nb) |
Nitrogen
(N) |
Aluminum
(Al) |
Tungsten
(W) |
Other
Elements |
|
T2 |
0.10–0.20 |
0.30–0.61 |
≤0.025 |
≤0.025 |
0.10–0.30 |
— |
0.50–0.81 |
0.44–0.65 |
— |
— |
— |
— |
— |
— |
— |
|
T5 |
≤0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
≤0.50 |
— |
4.00–6.00 |
0.45–0.65 |
— |
— |
— |
— |
— |
— |
— |
|
T5b |
≤0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
1.00–2.00 |
— |
4.00–6.00 |
0.45–0.65 |
— |
— |
— |
— |
— |
— |
— |
|
T5c |
≤0.12 |
0.30–0.60 |
≤0.025 |
≤0.025 |
≤0.50 |
— |
4.00–6.00 |
0.45–0.65 |
— |
— |
— |
— |
— |
— |
Ti (4×C–0.70) |
|
T9 |
≤0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
0.25–1.00 |
— |
8.00–10.00 |
0.90–1.10 |
— |
— |
— |
— |
— |
— |
— |
|
T11 |
0.05–0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
0.50–1.00 |
— |
1.00–1.50 |
0.44–0.65 |
— |
— |
— |
— |
— |
— |
— |
|
T12 |
0.05–0.15 |
0.30–0.61 |
≤0.025 |
≤0.025 |
≤0.50 |
— |
0.80–1.25 |
0.44–0.65 |
— |
— |
— |
— |
— |
— |
— |
|
T17 |
0.15–0.25 |
0.30–0.61 |
≤0.025 |
≤0.025 |
0.15–0.35 |
— |
0.80–1.25 |
— |
0.15 |
— |
— |
— |
— |
— |
— |
|
T21 |
0.05–0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
0.50–1.00 |
— |
2.65–3.35 |
0.80–1.06 |
— |
— |
— |
— |
— |
— |
— |
|
T22 |
0.05–0.15 |
0.30–0.60 |
≤0.025 |
≤0.025 |
≤0.50 |
— |
1.90–2.60 |
0.87–1.13 |
— |
— |
— |
— |
— |
— |
— |
|
T23 |
0.04–0.10 |
0.10–0.60 |
≤0.030 |
≤0.010 |
≤0.50 |
0.40 |
1.90–2.60 |
0.05–0.30 |
0.20–0.30 |
0.001–0.006 |
0.02–0.08 |
≤0.015 |
≤0.030 |
1.45–1.75 |
Ti controlled |
|
T24 |
0.05–0.10 |
0.30–0.70 |
≤0.020 |
≤0.010 |
0.15–0.45 |
— |
2.20–2.60 |
0.90–1.10 |
0.20–0.30 |
0.0015–0.007 |
— |
≤0.012 |
≤0.020 |
— |
Ti (0.06–0.10) |
|
T36 |
0.10–0.17 |
0.80–1.20 |
≤0.030 |
≤0.025 |
0.25–0.50 |
1.00–1.30 |
0.30 |
0.25–0.50 |
0.02 |
— |
0.015–0.045 |
≤0.020 |
≤0.050 |
— |
Cu (0.50–0.80) |
|
T91 |
0.07–0.14 |
0.30–0.60 |
≤0.020 |
≤0.010 |
0.20–0.50 |
0.40 |
8.0–9.5 |
0.85–1.05 |
0.18–0.25 |
— |
0.06–0.10 |
0.030–0.070 |
≤0.020 |
— |
Ti, Zr (trace) |
|
T92 |
0.07–0.13 |
0.30–0.60 |
≤0.020 |
≤0.010 |
≤0.50 |
0.40 |
8.5–9.5 |
0.30–0.60 |
0.15–0.25 |
0.001–0.006 |
0.04–0.09 |
0.030–0.070 |
≤0.020 |
1.5–2.00 |
Ti, Zr |
|
T122 |
0.07–0.14 |
≤0.70 |
≤0.020 |
≤0.010 |
≤0.50 |
0.50 |
10.0–11.5 |
0.25–0.60 |
0.15–0.30 |
0.0005–0.005 |
0.04–0.10 |
0.040–0.100 |
≤0.020 |
1.50–2.50 |
Cu, Ti, Zr |
|
T911 |
0.09–0.13 |
0.30–0.60 |
≤0.020 |
≤0.010 |
0.10–0.50 |
0.40 |
8.5–9.5 |
0.90–1.10 |
0.18–0.25 |
0.0003–0.006 |
0.06–0.10 |
0.040–0.090 |
≤0.020 |
0.90–1.10 |
Ti, Zr |
Chemical Composition Limits (%) (Stainless
Steel Grades)
|
Grade |
Carbon
(C) |
Manganese
(Mn) |
Phosphorus
(P) |
Sulfur
(S) |
Silicon
(Si) |
Chromium
(Cr) |
Nickel
(Ni) |
Molybdenum
(Mo) |
Nitrogen
(N) |
Niobium
(Nb) |
Titanium
(Ti) |
Other
Elements |
|
TP201 |
≤0.15 |
5.5–7.5 |
≤0.060 |
≤0.030 |
≤1.00 |
16.0–18.0 |
3.5–5.5 |
— |
≤0.25 |
— |
— |
— |
|
TP202 |
≤0.15 |
7.5–10.0 |
≤0.060 |
≤0.030 |
≤1.00 |
17.0–19.0 |
4.0–6.0 |
— |
≤0.25 |
— |
— |
— |
|
XM-19 |
≤0.06 |
4.0–6.0 |
≤0.045 |
≤0.030 |
≤1.00 |
20.5–23.5 |
11.5–13.5 |
1.50–3.00 |
0.20–0.40 |
0.10–0.30 |
— |
V (0.10–0.30) |
|
TP304 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
8.0–11.0 |
— |
— |
— |
— |
— |
|
TP304L |
≤0.035 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
8.0–12.0 |
— |
— |
— |
— |
— |
|
TP304H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
8.0–11.0 |
— |
— |
— |
— |
— |
|
TP304N |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
8.0–11.0 |
— |
0.10–0.16 |
— |
— |
— |
|
TP304LN |
≤0.035 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
8.0–11.0 |
— |
0.10–0.16 |
— |
— |
— |
|
TP309S |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
22.0–24.0 |
12.0–15.0 |
— |
— |
— |
— |
— |
|
TP309H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
22.0–24.0 |
12.0–15.0 |
— |
— |
— |
— |
— |
|
TP310S |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
24.0–26.0 |
19.0–22.0 |
— |
— |
— |
— |
— |
|
TP310H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
24.0–26.0 |
19.0–22.0 |
— |
— |
— |
— |
— |
|
TP316 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
16.0–18.0 |
10.0–14.0 |
2.00–3.00 |
— |
— |
— |
— |
|
TP316L |
≤0.035 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
16.0–18.0 |
10.0–14.0 |
2.00–3.00 |
— |
— |
— |
— |
|
TP316H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
16.0–18.0 |
11.0–14.0 |
2.00–3.00 |
— |
— |
— |
— |
|
TP316Ti |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤0.75 |
16.0–18.0 |
10.0–14.0 |
2.00–3.00 |
— |
— |
5×(C+N) |
— |
|
TP316N |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
16.0–18.0 |
10.0–13.0 |
2.00–3.00 |
0.10–0.16 |
— |
— |
— |
|
TP316LN |
≤0.035 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
16.0–18.0 |
10.0–13.0 |
2.00–3.00 |
0.10–0.16 |
— |
— |
— |
|
TP317 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
11.0–15.0 |
3.0–4.0 |
— |
— |
— |
— |
|
TP317L |
≤0.035 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
18.0–20.0 |
11.0–15.0 |
3.0–4.0 |
— |
— |
— |
— |
|
TP321 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–19.0 |
9.0–12.0 |
— |
— |
— |
Ti stabilized |
— |
|
TP321H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–19.0 |
9.0–12.0 |
— |
— |
— |
Ti stabilized |
— |
|
TP347 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–20.0 |
9.0–13.0 |
— |
— |
Nb (10×C) |
— |
— |
|
TP347H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–19.0 |
9.0–13.0 |
— |
— |
Nb |
— |
— |
|
TP348 |
≤0.08 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–19.0 |
9.0–13.0 |
— |
— |
Nb+Ta |
— |
— |
|
TP348H |
0.04–0.10 |
≤2.00 |
≤0.045 |
≤0.030 |
≤1.00 |
17.0–19.0 |
9.0–13.0 |
— |
— |
Nb+Ta |
— |
— |
|
Alloy 20 |
≤0.07 |
≤2.00 |
≤0.045 |
≤0.035 |
≤1.00 |
19.0–21.0 |
32.0–38.0 |
2.0–3.0 |
— |
— |
— |
Cu (3–4) |
|
800 |
≤0.10 |
≤1.50 |
≤0.045 |
≤0.015 |
≤1.00 |
19.0–23.0 |
30.0–35.0 |
— |
— |
— |
Al, Ti |
Fe balance |
|
800H |
0.05–0.10 |
≤1.50 |
≤0.045 |
≤0.015 |
≤1.00 |
19.0–23.0 |
30.0–35.0 |
— |
— |
— |
Al, Ti |
Fe balance |
|
800HT |
0.06–0.10 |
≤1.50 |
≤0.045 |
≤0.015 |
≤1.00 |
19.0–23.0 |
30.0–35.0 |
— |
— |
— |
Al+Ti control |
Fe balance |
|
904L |
≤0.020 |
≤2.00 |
≤0.040 |
≤0.030 |
≤1.00 |
19.0–23.0 |
23.0–28.0 |
4.0–5.0 |
≤0.10 |
— |
— |
Cu (1–2) |
|
926 |
≤0.020 |
≤2.00 |
≤0.030 |
≤0.010 |
≤0.50 |
19.0–21.0 |
24.0–26.0 |
6.0–7.0 |
0.15–0.25 |
— |
— |
Cu |
Mechanical Properties
|
Grade |
Tensile Strength
(MPa) |
Yield Strength
(MPa) |
Elongation (%) |
|
T5 |
≥ 415 |
≥ 205 |
≥ 30 |
|
T9 |
≥ 585 |
≥ 415 |
≥ 20 |
|
T11 |
≥ 415 |
≥ 205 |
≥ 30 |
|
T22 |
≥ 415 |
≥ 205 |
≥ 30 |
|
TP304 |
≥ 515 |
≥ 205 |
≥ 35 |
|
TP316 |
≥ 515 |
≥ 205 |
≥ 35 |
Key Features of ASTM A213 Alloy Steel Tubes
Suitable for
high-temperature and high-pressure service
Excellent oxidation and corrosion resistance
High creep strength for long-term performance
Uniform structure and precise dimensions
Good weldability and formability
Wide range of ferritic and austenitic grades
Ideal for critical heat transfer applications
Applications of ASTM A213 Alloy Steel Tubes
ASTM A213 tubes are widely used in industries requiring heat resistance,
strength, and corrosion resistance.
Power Plants
• Boiler tubes
• Superheater tubes
• Economizer tubes
Heat
Exchangers
• Condenser tubes
• Heat transfer systems
Petrochemical
Industry
• Process heating equipment
• Refinery piping systems
Industrial
Boilers
• Steam generation systems
• Thermal plants
Heat Treatment
Ferritic
grades are typically normalized and tempered
Austenitic grades are solution annealed
Heat treatment improves strength, ductility, and corrosion resistance
Ensures uniform microstructure and performance
Conclusion
ASTM A213 /
A213M seamless alloy steel tubes offer a versatile and reliable solution for
boiler, superheater, and heat exchanger applications. With a wide range of
ferritic and austenitic grades, these tubes deliver excellent performance in
high-temperature, high-pressure, and corrosive environments.
Ladhani
Metal Corporation supplies ASTM A213 / A213M alloy steel tubes in multiple
grades and sizes, ensuring premium quality products for power generation,
petrochemical processing, and industrial heating systems.
FOR REQUIREMENT OF THIS GRADE OR FOR DETAIL CONTACT US AT :-
#ASTMA213 #ASTMA213M #AlloySteelTubes
#SeamlessTubes #BoilerTubes #SuperheaterTubes #HeatExchangerTubes
#AlloySteelPipe #IndustrialTubes #HighTemperatureSteel #PressureTubes
#PowerPlantTubes #OilAndGasTubes #PetrochemicalIndustry #RefineryTubes
#EnergySector #ThermalPowerPlant #EngineeringSteel #SteelIndustry
#MetalIndustry #TubeManufacturer #SteelSupplier #PipeSupplier
#IndustrialMaterials #HeavyEngineering #HeatResistantSteel
#CorrosionResistantSteel #SeamlessPipe #PrecisionTubes #BoilerApplications #ProcessIndustry
#ManufacturingIndia #SteelExport #MetalSupplier #TubeIndustry #IndustrialPiping
#SteelProducts #AlloyGrades #ASTMStandards #QualitySteel #DurableSteel
#HighPressureTubes #HeatTransferTubes #PowerGeneration #IndustrialSolutions
#LadhaniMetal #AlloyTubeSolutions #SteelFabrication #EngineeringMaterials
#GlobalSupply #Mumbai #Delhi #Chennai #Kolkata #Bengaluru #Hyderabad #Ahmedabad
#Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore #Thane #Bhopal
#Visakhapatnam #Patna #Vadodara #Ghaziabad #Ludhiana #Coimbatore #Agra #Madurai
#Nashik #Faridabad #Meerut #Rajkot #Varanasi #Srinagar #Aurangabad #Dhanbad
#Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah #Jabalpur #Gwalior #Vijayawada
#Jodhpur #Raipur #Kota #Guwahati #Chandigarh #Solapur #Hubli #Mysuru
#Tiruchirappalli #Bareilly
@Mumbai @Delhi @Chennai @Kolkata
@Hyderabad @Bengaluru
