Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI VCMO150 725 1.7228 50CrMo4 50CrMo4 4150 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.50 max. 0.40 0.65 1.05 0.23 - - - - DescriptionThis is a higher carbon variation of the chromium, manganese, molybdenum 4100 series of low alloy steels.  ApplicationsStatically and dynamically stressed components for vehicles, engines and machines, for parts of larger cross-sections. Components for driv...

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 This is a higher carbon variation of the chromium, manganese, molybdenum 4100 series of low alloy steels.

Applications
 Statically and dynamically stressed components for vehicles, engines and machines, for parts of larger cross-sections. Components for driving gears, axles, rolls, rings.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 190-210
 Density [g/cm³]: 7.84

Continuous Cooling Transformation (CCT) Diagram

Time-Temperature Transformation (TTT) Diagram

Soft Annealing
 Heat to 680-720^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 248.

Hardening
 Hardening: 820-850, 830-860^oC, water, oil.

Normalizing
 Normalizing: 840-860^oC

Tempering
 Tempering temperature: 540-680^oC

Hardness after heat treatmnet
 Aannealed at 815^oC: 197 HB
 Normalized at 870^oC: 321 HB
 Oil quenched, fine grained, tempered at 205^oC: 530 HB
 Oil quenched, fine grained, tempered at 315^oC: 495 HB
 Oil quenched, fine grained, tempered at 425^oC: 440 HB
 Oil quenched, fine grained, tempered at 540^oC: 370 HB
 Oil quenched, fine grained, tempered at 650^oC: 290 HB

Mechanical Properties in Hardening and Tempering Condition

Diagram Tempering Temperature – Mechanical Properties

Forging
 Hot forming temperature: 1050-850^oC.

Machinability
 Machinability of 4150 is good in the annealed condition, or in the normalized condition. After heat treatment the alloy can be very hard and it is best to limit machining at that point to grinding.

Corrosion Resistance
 This is not a corrosion resistant alloy. Use protective coating.

Welding
 The alloy may be welded by conventional methods. Welding the alloy in the hardened (heat treated) condition may affect the mechanical properties due to welding heat input. A post-weld heat treatment may be needed. Follow an approved weld procedure.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
