Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.3503 105Cr4 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 1.05 0.25 0.33 1.03 - - - - - Description Low alloyed Cr cold working tool steel. Applications For balls, rollers, links with diameter up to 10-17 mm.  Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210  Density [g/cm3]: 7.80 Soft Annealing Heat to 730-760oC, cool slowly. This will produce a maximum Bri...

·FOB Price:US $0.5 - 9,999 / Piece

·Min.Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms:L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 Low alloyed Cr cold working tool steel.

Applications
 For balls, rollers, links with diameter up to 10-17 mm.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 210
 Density [g/cm³]: 7.80

Soft Annealing
 Heat to 730-760^oC, cool slowly. This will produce a maximum Brinell hardness of 207.

Normalizing
 Temperature: 860-890^oC.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to 600-650^oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 Harden from a temperature of 790-820, 820-850^oC followed by water or oil quenching or warm bath approx. 400^oC. Hardness after quenching is 65 HRC.

Tempering
 Tempering temperature: 150-170^oC.

Tempering Temperature (^oC) vs. Hardness (HRC)

Tempering Diagram

Forging
 Hot forming temperature: 1100-850^oC.

Machinability
 No data.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available
