Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.3346 S2-9-1 - M1 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.82 max. 0.45 max. 0.40 3.85 8.60 - 1.15 1.75 - Description M1 is a molybdenum, chromium, vanadium alloy tool steel generally known as a Molybdenum High Speed Tool Steel. It is on of the most widely available tool steels in use today. It is similar in properties to the tungsten tool steels (T series) at a lower. Very tough high-speed Mo steel good gr...

·FOB Price:US $0.5 - 9,999 / Piece

·Min.Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms:L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 M1 is a molybdenum, chromium, vanadium alloy tool steel generally known as a Molybdenum High Speed Tool Steel. It is on of the most widely available tool steels in use today. It is similar in properties to the tungsten tool steels (T series) at a lower. Very tough high-speed Mo steel good grindability.

Applications
 Twist drills, thread cutting tools, hobs and dies for broaching and cold flow pressing, cross recess dies for screw manufacture, cold rolling for e.g. Sendzimir equipment.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 217
 Density [g/cm³]: 8.0
 Thermal conductivity [W/m.K]: 19.0
 Electric resistivity [Ohm mm²/m]: 0.60
 Specific heat capacity[J/g.K]: 0.46

Coefficient of Linear Thermal Expansion 10^-6oC^-1

Continuous Cooling Transformation (CCT) Diagram

Click the image to enlarge the diagram.

Soft Annealing
 Heat to 820-850^oC, cool slowly in furnace to 550^oC then air. This will produce a maximum Brinell hardness of 262.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to 600-650^oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 0 Harden from a temperature of 1180-1219^oC followed by air or oil quenching or warm bath at 550^oC. Hardness after quenching is 64-66 HRC.

Tempering
 Tempering temperature: 530 – 560^oC, at least 2x for at least 63 HRC.

Tempering Diagram

 Click the image to enlarge the diagram.

Forging
 Hot forming temperature: 1100-900^oC.

Cold Working
 This alloy may be cold worked in the annealed condition.

Machinability
 M1 is classified as a “medium” machinable alloy. Machining should be accomplished prior to hardening heat treatment followed by finish grinding. It has a rating of 50% that of the water hardening (W group) low alloy tool steels in regard to machinability.

Corrosion Resistance
 This is not a corrosion resistant alloy. In use as tooling it is often coated with oil to prevent rusting. A light film of oil. or protective wrapping, is essential to keep it free from corrosion.

Welding
 Consult the alloy supplier for information on weld procedures.

Forms manufactured: Please see the Dimensional Sales Program.
