Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.2631 X50CrMoW9-1-1 - -   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 0.50 0.90 0.50 8.50 1.20 - - 1.20 -   Description Cold work tool steel. High toughness and resistance to dynamic loading. Applications Severely stressed machine blades for the cellulose, paper and fiberboard industries, flat-blade and circular blades for cutting 5 to 15 mm thick sheet/plate. Physical properties (...

·FOB Price:US $0.5 - 9,999 / Piece

·Min.Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms:L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 Cold work tool steel. High toughness and resistance to dynamic loading.

Applications
 Severely stressed machine blades for the cellulose, paper and fiberboard industries, flat-blade and circular blades for cutting 5 to 15 mm thick sheet/plate.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 210
 Density [g/cm³]: 7.80
 Thermal conductivity [W/m.K]: 26.0
 Electric resistivity [Ohm mm²/m]: 0.60
 Specific heat capacity[J/g.K]: 0.46

Coefficient of Linear Thermal Expansion 10^-6oC^-1

Continuous Cooling Transformation (CCT) Diagram

Soft Annealing
 Heat to 820-870^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 250.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to approx. 650^oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 Harden from a temperature of 1020-1050^oC followed by oil, air or warm bath (approx. 400^oC.) quenching. Hardness after quenching is 61 HRC.

Tempering
 Tempering temperature: 150-400^oC

Tempering Temperature (^oC) vs. Hardness (HRC)

Tempering Diagram

Forging
 Hot forming temperature: 1050-900^oC.

Machinability
 No data.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
