1.2363, DIN X100CrMoV5-1, AISI A2 Bar Manufacturer , Supplier , Exporter

1.2363, DIN X100CrMoV5-1, AISI A2 Bar Manufacturer , Supplier , Exporter

CONTACT US FOR MORE DETAILS



www.ladhanimetal.com
www.ladhanimetal.in
ladhanimetal@gmail.com


LADHANI METAL CORPORATION, MUMBAI, INDIA

Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.2363 X100CrMoV5-1 - A2   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 1.00 0.25 0.60 5.15 1.05 - 0.20 - -   Description This alloy is one of the cold work, medium air hardening type tool steels. It contains chromium and molybdenum with a relatively high (1 %) carbon content and is capable of deep hardening from air quench so as to minimize distortion. Applications Used of die shape...

·FOB Price: US $0.5 - 9,999 / Piece

·Min. Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms: L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 This alloy is one of the cold work, medium air hardening type tool steels. It contains chromium and molybdenum with a relatively high (1 %) carbon content and is capable of deep hardening from air quench so as to minimize distortion.

Applications
 Used of die shapes, slitters, cutting, stamping, injection tools and similar applications where wear resistance is important

Physical properties (avarage values) at ambient temperature
 Density [g/cm³]: 7.70
 Thermal conductivity [W/m.K]: 26.0

Coefficient of Linear Thermal Expansion 10^-6oC^-1

Continuous Cooling Transformation (CCT) Diagram

Time-Temperature Transformation (TTT) Diagram

Soft Annealing
 Heat to 800-840^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 230.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to 650^oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 Harden from a temperature of 930-970^oC followed by air, oil, warm bath (500-550^oC) quenching. Hardness after quenching is 63 HRC.

Tempering
 Tempering temperature: 150-550^oC

Tempering Temperature (^oC) vs. Hardness (HRC)

Tempering Diagram

Forging
 Hot forming temperature: 1050-850^oC.

Machinability
 Machinability is medium, about 85 % that of the W group of tool steels which are rated at 100% for a baseline.

Corrosion Resistance
 Corrosion resistance of this alloy is better than that of plain carbon steels. However it will rust unless given protective treatment.

Welding
 This is an alloy steel and thus capable of being welded. Consult the alloy supplier for welding procedures.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
