Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.2362 X63CrMoV51 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.63 1.10 0.40 5.25 1.0 0.30 - - - Description Cr-Mo alloyed through hardening steel with high tempering resistance. Applications Intermediate rolls for cluster mills, trimming dies, hot cutting shears.  Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210  Density [g/cm3]: 7.81 Continuous Cooling Tra...

·FOB Price:US $0.5 - 9,999 / Piece

·Min.Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms:L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 Cr-Mo alloyed through hardening steel with high tempering resistance.

Applications
 Intermediate rolls for cluster mills, trimming dies, hot cutting shears.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 210
 Density [g/cm³]: 7.81

Continuous Cooling Transformation (CCT) Diagram

Soft Annealing
 Heat to 800-840^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 250.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to 600-650^oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 Harden from a temperature of 980-1020^oC followed by oil quenching or warm bath quenching. Hardness after quenching is 61-63 HRC.

Tempering
 Tempering temperature: See the data bellow.

Tempering Temperature (^oC) vs. Hardness (HRC)

Tempering Diagram



Forging

 Hot forming temperature: 1100-850^oC.

Machinability
 No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
