Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.2201 X165CrV12 - -   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 1.65 0.32 0.40 11.50 - - 0.10 - -   Description Ledeburitic cold work tool steel with high wear resistance and good toughness. Applications Cutting and die tools, saw rolls, etc. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.80 Continuous Cooli...

·FOB Price: US $0.5 - 9,999 / Piece

·Min. Order Quantity:100 Piece/Pieces

·Supply Ability:10000 Piece/Pieces per Month

·Port: Mumbai

·Payment Terms: L/C,D/A,D/P,T/T

Send email to usDownload as PDF

Product Detail

Designation by Standards

Chemical Composition (in weight %)

Description
 Ledeburitic cold work tool steel with high wear resistance and good toughness.

Applications
 Cutting and die tools, saw rolls, etc.

Physical properties (avarage values) at ambient temperature
 Modulus of elasticity [10³ x N/mm²]: 210
 Density [g/cm³]: 7.80

Continuous Cooling Transformation (CCT) Diagram

Time-Temperature Transformation (TTT) Diagram

Soft Annealing
 Heat to 820-850^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 250.

Stress Relieving
 Stress relieving to remove machining stresses should be carried out by heating to about 650^oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
 Harden from a temperature of 960-980^oC followed by oil quenching or warm bath quenching 350-400^oC. Hardness after quenching is approx.. 63 HRC.

Tempering
 Tempering temperature: See the data bellow.

Tempering Temperature (^oC) vs. Hardness (HRC)

Tempering Diagram

Forging
 Hot forming temperature: 1050-850^oC.

Machinability
 No data.

Disclaimer
 The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
