Introduction
EN
10016-4 specifies non-alloy steel rod & wire intended for drawing and/or cold rolling.
These steel rods are supplied with controlled chemical composition, dimensional
accuracy, surface quality, and mechanical properties suitable for subsequent
cold working and the production of wire and other engineered steel products.
EN
10016-4 steel rod is used in wire manufacturing, cold-drawn products,
fasteners, mechanical components, automotive components, construction products,
and general engineering applications.
Ladhani
Metal Corporation is a manufacturer, supplier, and exporter of EN 10016-4
Non-Alloy Steel Rod for Drawing and/or Cold Rolling, supplying steel rod in
different grades, diameters, surface conditions, and customized requirements
worldwide.
Applicable Standard
Standard
Specification: EN 10016-4
Organization:
European Committee for Standardization (CEN)
Title:
Non-Alloy Steel Rod for Drawing and/or Cold Rolling
EN
10016-4 covers non-alloy steel rod intended for subsequent drawing and/or cold
rolling operations.
Forms of Supply
•
Non-Alloy Steel Rod
• Steel Rod for Drawing
• Steel Rod for Cold Rolling
• Wire Rod
• Cold-Working Rod
• Drawing Quality Rod
• Cold Rolling Quality Rod
• Straight Length Rod
• Coil Rod
Supply Condition
•
Hot Rolled Condition
• As-Rolled Condition
• Drawing Quality Condition
• Cold Rolling Quality Condition
• Pickled Condition
• Surface Condition as Specified
Surface Finish
•
Hot Rolled Surface
• Pickled Surface
• Descaled Surface
• Smooth Surface
• Drawing Quality Surface
• Cold Rolling Quality Surface
Standard Sizes
Steel Rod
Diameter:
Commonly supplied in approximately 5 mm to 100 mm range
Length:
Standard and customer-specified lengths
Coil
Weight: According to manufacturing and customer requirements
Custom
diameters, lengths, coil weights, and surface conditions are available
according to customer requirements.
Chemical
Composition of EN 10016-4
|
Steel Name |
C
% |
Si
% |
Mn
% |
P
% max. |
S
% max. |
Cr
% max. |
Ni
% max. |
Mo
% max. |
Cu
% max. |
Al
% max. |
N
% max. |
|
C3D2 |
≤ 0,05 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C5D2 |
≤ 0,07 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C8D2 |
0,06–0,10 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C10D2 |
0,08–0,12 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C12D2 |
0,10–0,14 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C15D2 |
0,13–0,17 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C18D2 |
0,16–0,20 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C20D2 |
0,18–0,23 |
≤ 0,30 |
0,30–0,50 |
0,020 |
0,025 |
0,10 |
0,10 |
0,05 |
0,15 |
0,01 |
0,007 |
|
C26D2 |
0,24–0,29 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C32D2 |
0,30–0,34 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C36D2 |
0,34–0,38 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C38D2 |
0,36–0,40 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C40D2 |
0,38–0,42 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C42D2 |
0,40–0,44 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C46D2 |
0,44–0,48 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C48D2 |
0,46–0,50 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C50D2 |
0,48–0,52 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C52D2 |
0,50–0,54 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C56D2 |
0,54–0,58 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C58D2 |
0,56–0,60 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C60D2 |
0,58–0,62 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C62D2 |
0,60–0,64 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C66D2 |
0,64–0,68 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C68D2 |
0,66–0,70 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C70D2 |
0,68–0,72 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,03 |
0,15 |
0,01 |
0,007 |
|
C72D2 |
0,70–0,74 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C76D2 |
0,74–0,78 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C78D2 |
0,76–0,80 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C80D2 |
0,78–0,82 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C82D2 |
0,80–0,84 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C86D2 |
0,84–0,88 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C88D2 |
0,86–0,90 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C92D2 |
0,90–0,95 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
|
C98D2 |
0,96–1,00 |
0,10–0,30 |
0,50–0,70 |
0,020 |
0,025 |
0,10 |
0,10 |
0,02 |
0,15 |
0,01 |
0,007 |
Notes
- Elements not included in this table
may not be added intentionally to the steel without the agreement of the
purchaser, except those intended for finishing the cast.
- The addition of microalloying
elements can be agreed between the manufacturer and purchaser at the time
of ordering.
- Special non-alloy steel according
to EN 10020.
- For rod intended for galvanization,
the allowed lower limit of silicon content should be specified at the time
of ordering.
- For the manganese content, a
different range from the one indicated in the table can be agreed at the
time of ordering with a maximum value not exceeding 1,20 % and with an
amplitude of 0,20 %.
- The sum of the contents Cu + Ni +
Cr shall not exceed 0,30 %.
- Cu + Sn ≤ 0,15 %.
- For certain applications, the Cu
content may be restricted to 0,12 % max., by agreement.
- By agreement at the time of
ordering, the value for aluminium can be fixed at 0,02 to 0,06 %. The
value for silicon can then be fixed at ≤ 0,10 % on request.
- If, in accordance with Note 9, the
Al content is fixed at 0,02 to 0,06 %, the limit value for N shall be
agreed at the time of ordering.
Key Features of EN
10016-4 Steel Rod
•
Excellent cold-working suitability
• Good drawing characteristics
• Suitable for cold rolling
• Controlled chemical composition
• Good surface quality
• Excellent dimensional accuracy
• Consistent metallurgical structure
• Good machinability depending on grade
• Suitable for wire production
• Reliable mechanical performance
Applications of EN
10016-4 Steel Rod
Wire Manufacturing Industry
•
Cold Drawn Wire
• Steel Wire Products
• Industrial Wire
• Mechanical Wire
• Precision Wire
Automotive Industry
•
Automotive Components
• Fasteners
• Mechanical Parts
• Formed Components
• Wire Products
Construction Industry
•
Fasteners
• Steel Components
• Reinforcement Products
• Structural Wire Products
Mechanical Engineering
•
Machine Components
• Cold-Formed Parts
• Precision Components
• Engineering Products
• Industrial Components
General Manufacturing
•
Bolts and Fasteners
• Pins
• Small Shafts
• Wire Products
• Cold-Rolled Components
Fabrication and
Cold Working
EN
10016-4 steel rod is specifically intended for subsequent drawing and/or cold
rolling operations.
•
Suitable for cold drawing
• Suitable for cold rolling
• Good dimensional control after processing
• Excellent surface requirements for cold working
• Suitable for wire production
• Good formability according to carbon content
• Suitable for precision manufacturing
The
appropriate drawing or cold-rolling process should be selected according to the
steel grade and required final properties.
Heat Treatment
Heat
treatment depends on the selected steel grade and subsequent manufacturing
process.
•
Annealing can improve ductility
• Normalizing can refine the microstructure
• Controlled cooling supports consistent properties
• Heat treatment may be applied before subsequent cold working
• Process-specific heat treatment can improve formability
Advantages of EN
10016-4 Steel Rod
•
Excellent suitability for drawing
• Suitable for cold rolling
• Good surface quality
• Controlled dimensional tolerances
• Consistent chemical composition
• Reliable mechanical properties
• Wide range of carbon steel grades
• Suitable for wire production
• Good cold-forming characteristics
• Cost-effective material for industrial manufacturing
Conclusion
EN
10016-4 Non-Alloy Steel Rod for Drawing and/or Cold Rolling is designed for
subsequent cold-working operations including drawing and cold rolling. The
steel rod provides controlled chemical composition, suitable surface quality,
dimensional accuracy, and reliable processing characteristics for wire
manufacturing, automotive components, fasteners, mechanical engineering,
construction products, and general industrial applications.
Ladhani Metal Corporation supplies EN
10016-4 Non-Alloy Steel Rod in various grades, diameters, surface conditions,
lengths, and coil configurations, providing reliable steel rod solutions for
drawing, cold rolling, wire manufacturing, and precision engineering
applications worldwide.
FOR REQUIREMENT OF THIS GRADE
OR FOR DETAIL CONTACT US AT :-
#EN100164
#EN10016Part4 #EN100164SteelRod #EN100164NonAlloySteel #NonAlloySteelRod
#SteelRodForDrawing #SteelRodForColdRolling #ColdRollingSteelRod
#DrawingQualitySteel #CarbonSteelRod #LowCarbonSteelRod #SteelWireRod
#ColdDrawnSteel #ColdRolledSteel #PrecisionSteelRod #EngineeringSteelRod
#IndustrialSteelRod #SteelRodManufacturer #SteelRodSupplier #SteelRodExporter
#CarbonSteelSupplier #NonAlloySteelSupplier #SteelWireRodManufacturer
#SteelWireRodSupplier #ColdWorkingSteel #MetalDrawingMaterials
#EngineeringMaterials #EuropeanSteelStandard #LadhaniMetals #SteelRodSolutions #Mumbai #Delhi #Chennai #Kolkata #Bengaluru
#Hyderabad #Ahmedabad #Pune #Surat #Jaipur #Lucknow #Kanpur #Nagpur #Indore
#Srinagar #Aurangabad #Dhanbad #Amritsar #NaviMumbai #Allahabad #Ranchi #Howrah
#Jabalpur #Gwalior #Vijayawada #Jodhpur #Raipur #Kota #Guwahati #Chandigarh
#Solapur #Hubli #Mysuru #Tiruchirappalli #Bareilly
@Mumbai
@Delhi @Chennai @Kolkata @Hyderabad @Bengaluru
