Titanium couplings and nipples are essential components used in piping systems to connect, extend, or adapt pipes. Renowned for their outstanding strength, corrosion resistance, and durability, titanium fittings are widely utilized in high-performance industries such as aerospace, marine, chemical processing, and power generation. The unique properties of titanium ensure that these fittings offer long-lasting, reliable service in demanding applications. Titanium Coupling A titanium coupling is a pipe fitting used to join two pipes or tubes together. They are designed to connect the same or different diameter pipes, allowing for a seamless, leak-proof connection. Titanium couplings offer exceptional resistance to corrosion, high strength, and are lightweight, making them ideal for use in environments exposed to harsh conditions like seawater, chemical exposure, or high temperatures. Titanium Nipple A titanium nipple is a short, cylindrical pipe section that is typically threaded on both ends to allow for easy connection of pipes. It serves as an extension or connection between two other fittings or pipes, offering a secure and stable joint. Like other titanium components, titanium nipples offer the advantage of corrosion resistance, strength, and durability, making them suitable for challenging applications across various industries. Titanium Couplings and Nipples – Mechanical Specifications Material: Grade: Typically Grade 2 (commercially pure titanium) or Grade 5 (Ti-6Al-4V, titanium alloy) depending on the application requirements. Standard: ASTM B337, ASTM B348, or equivalent. Tensile Strength: Grade 2 (Pure Titanium): 35,000 – 50,000 psi (240 – 345 MPa). Grade 5 (Ti-6Al-4V): 130,000 psi (900 MPa). Yield Strength: Grade 2 (Pure Titanium): 20,000 – 40,000 psi (138 – 276 MPa). Grade 5 (Ti-6Al-4V): 120,000 psi (828 MPa). Elongation: Grade 2 (Pure Titanium): 20-25%. Grade 5 (Ti-6Al-4V): 10-15%. Hardness: Grade 2 (Pure Titanium): 170-230 HV (Vickers hardness). Grade 5 (Ti-6Al-4V): 300-400 HV (Vickers hardness). Types of Titanium Couplings: Threaded Couplings: Used to connect pipes with matching threads, providing a secure and easy-to-assemble connection. Common for low-pressure systems. Socket Weld Couplings: Welded into the socket of connecting pipes, ideal for high-pressure applications, offering a permanent, strong connection. Butt Weld Couplings: Have flared ends for welding to pipes, commonly used in high-pressure systems for a smooth and durable connection. Flanged Couplings: Connect pipes via flanges and bolts with a gasket for a high-pressure, leak-proof connection. Suitable for large-scale industrial applications. Types of Titanium Nipples: Threaded Nipples: Cylindrical pipes with male threads at both ends, used to extend or connect pipes. Easy to install and remove. Socket Weld Nipples: One end fits into a socket for welding, designed for high-pressure systems, offering a permanent and robust connection. Butt Weld Nipples: Used to connect pipes by welding, offering a seamless and high-strength connection for high-pressure systems. Reducing Nipples: Connect pipes of different diameters, allowing for transitions between pipe sizes in fluid systems. Extension Nipples: Extend the length of a pipeline, used in systems requiring adjusted pipe alignment or spacing. Hex Nipples: Have a hexagonal shape for easy tightening and installation without tools, commonly used in fluid and gas systems.

Product Name: Gr7 Titanium sheet Standard: ASTM B265 Material: Gr7 Unit Price: $222.5usd/kg-$285.7usd/kg Thickness: 0.5-100mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Surface: Pickling, Polishing, Sand Blasting Gr7 titanium sheet is high palladium content, and it is very resistant to corrosion. For example, titanium grade 7 is resistant to salt water and is also suitable for handling chlorides media. In addition, Titanium Grade 7 is resistant to erosion or impacts. plate usually used for Pressure vessel, fastener, frame, Aerospace vehicle, Chemical industry, ocean engineering etc.

Product Name:Titanium Sheet AMS 4901 Standard: AMS 4911 Material: Gr5 Unit Price: $18.5usd/kg-$48usd/kg Thickness: 0.3-6mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Surface: Pickling, Polishing, Sand Blasting

Product name:6-6-2 titanium sheet Standard:ASTM/ASME B265 Material:Ti-6Al-6V-2Sn-0.5Cu-0.5Fe Demension: Thickness*1000*2000mm Thickness*3000*6000mm (Standard size),or as customers' requests Thickness: 0.5mm; 0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 3.0mm; 4.0mm ......40mm etc Technique : Rolled

Name: Titanium sheet Standard: ASTM B265 Grade: Gr3

Product name:Titanium sheet Grades: Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr12, Gr23 Standard: ASTM B265/ASME B265 AMS 4911 ASTM F67 ASTM F136 Dimension： Thickness*Width:200-3000mm*Length:500-6000mm Supply status: Annealed(M) Package: Carton or plywood case. MTC: EN10204.3.1 certificate There is Grade 1, Grade 2, Grade 3, Grade4, Grade5, Grade 7, Grade 12 titanium plates in stock. Titanium plate is widely used in various fields, including metallurgy, electronics, medical, chemical, petroleum, medicine, aerospace, etc.. We offer competitive prices online, available incutting size as customers' requets. 1, Specifications Thickness range: 0.5mm-200mm Titanium coil plate/titanium coil strip: 0.1mm-0.5mm thick *1m/1.2m/1.5m wide. Standard plate: 0.5mm-20mm thick *1m*2m. Cold rolled plate: 1mm-4mm*1m*2m hot rolled plate: above 4mm thick wide and thick plate: above 5mm *2m*6m is a common specification, and specific specifications can also be customized according to customer requirements. 2, Material TA1 (Grade 1), TA2 (Grade 2), TA9 (Grade 7), TA10 (Grade 12), TA18 TC4 (Grade 5), TC6 and TC11 3.Standard dimension in stock: 1000 mm Width * 2000 mm Length 1500 mm Width* 6000 mm Length 2000 mm Width* 6000 mm Length 4,Surface:Pickled, polished, sand-blasted

Product Name: Gr7 Titanium sheet Standard: ASTM B265 Material: Gr7 Unit Price: $222.5usd/kg-$285.7usd/kg Thickness: 0.5-100mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Surface: Pickling, Polishing, Sand Blasting Gr7 titanium sheet is high palladium content, and it is very resistant to corrosion. For example, titanium grade 7 is resistant to salt water and is also suitable for handling chlorides media. In addition, Titanium Grade 7 is resistant to erosion or impacts. plate usually used for Pressure vessel, fastener, frame, Aerospace vehicle, Chemical industry, ocean engineering etc. Product Name: Gr7 Titanium sheet Standard: ASTM B265 Material: Grade 7 (Ti-0.2Pd) Thickness: 0.5-100mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Surface: Pickling, Polishing, Sand Blasting Quality inspections: Flaw detection, eddy current test, etc Grade Chemicai composition(WT%) (Ti) (Fe) (C) (N) (H) (O) (Pd) (Al) (Sn) Others Each Total Gr7 Ti-0.2Pd Remainder ≤0.30 ≤0.08 ≤0.03 ≤0.015 ≤0.25 0.12～0.25 / / ≤0.1 ≤0.4

Product name:Titanium sheet for knife making Grades: Gr5(Ti6Al4V) Standard: ASTM B265/ASME B265 Dimension： Thickness*Width:200-3000mm*Length:500-6000mm Supply status: Annealed(M) Package: Carton or plywood case Usually, the titanium alloy plate used for knife is Grade 5 (Ti6Al4V). This grade titanium material is one of the most widely used materials in titanium alloys. It has the same advantages as pure titanium: corrosion resistance, non-toxic, light weight, etc. There are also many of other advantages over pure titanium: higher hardness, tensile strength, yield strength and elongation. Can meet the needs of making knife. Titanium is a good material for knives if your main concern is light weight and corrosion resistance. Titanium knives are ideal for anyone who spends a lot of time around water or performs jobs that require frequent blade cleaning. Product name:Titanium sheet for knife making Grades: Gr5(Ti6Al4V) Standard: ASTM B265/ASME B265 Dimension： Thickness1-150mm*Width:200-3000mm*Length:500-6000mm Supply status: Annealed(M) Package: Carton or plywood case. MTC: EN10204.3.1 certificate MOQ : 10kgs Titanium plate applications

Product name:Titanium sheet metal Unit price:$14-$36.9/kg Material: Titanium grade 1 grade 2 grade 3 grade 4 Grade 5 (Ti6al4v),grade 7,grade 12 etc. Standard: ASTM/ASME B265 AMS 4911 ASTM F136 ASTM F67 etc. Demension: Thickness*1000*2000mm Thickness*3000*6000mm (Standard size); Thickness: 0.5mm; 0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 3.0mm; 4.0mm ......40mm etc br>Technique : Rolled Status: Annealed(M) Titanium has many obviously superior characteristics: small density (4.5kg/m3), high melting point (1660℃), strong corrosion resistance, high specific strength, good plasticity, but also through alloying and heat treatment methods to produce a variety of alloys with high mechanical properties, is an ideal aerospace engineering structural materials. Titanium sheet metal are commonly used in today's manufacturing industry, and the most commonly used grades are 2 and 5. Grade 2 titanium Grade 2 is commercial pure titanium used in most chemical processing plants and can be cold formed. Ultimate tensile strength of grade 2 plates and sheets up to 40,000 psi and above. Grade 5 titanium Class 5 is an aerospace class that does not allow cold molding and is therefore used more often when molding is not required. Grade 5 aerospace alloys have ultimate tensile strength of 120,000 psi and above. Usually the purpose of using Titanium sheet metal is to really approximate the final size of the part being manufactured. The material is processed to the nearest size of the required parts and the grain structure of the finished product is more uniform. Titanium plates are often used as insulation because titanium prevents heat from being transferred to the rest of the assembly. The titanium plate and titanium plate are bulletproof and provide good protection for the driver during the race. Application example: in addition to the use of industrial pure titanium manufacturing parts, a large number of titanium alloy is used. It is increasingly widely used in aerospace, aerospace, chemical, shipbuilding and other industrial sectors, manufacturing gas turbine components, the production of prosthetic devices and other biological materials
