Aerospace Titanium Specifications (AMS 49) AMS 4900 Plate, Sheet & Strip – Annealed –55,000 psi Yield AMS 4901 Sheet, Strip & Plate – Annealed – 70,000 psi Yield AMS 4902 Plate, Sheet & Strip – Annealed – 40,000 psi Yield AMS 4905 Plate, Damage Tolerant Grade – 6AI 4V, Beta Annealed AMS 4907 Plate, Sheet & Strip – 6Al-4V, Extra Low Interstitial, Annealed AMS 4908 Sheet & Strip – 8Mn Annealed - 110,000 psi Yield AMS 4909 Plate, Sheet & Strip – 5Al-2.5Sn, Extra Low Interstitial, Annealed AMS 4910 Plate, Sheet & Strip – 5Al-2.5Sn, Annealed AMS 4911 Sheet, Strip & Plate – 6Al-4V, Annealed AMS 4914 Sheet & Strip – 15V 3Cr 3Sn #AI – Solution Heat Treated AMS 4915 Plate, Sheet & Strip – 8Al-1Mo-1V – Single Annealed AMS 4916 Plate, Sheet & Strip – 8Al-1Mo-1V – Duplex Annealed AMS 4917 Plate, Sheet & Strip – 13.5V 11Cr 3Al – Solution Treated AMS 4918 Plate, Sheet & Strip –6Al-6V-2Sn – Annealed AMS 4919 Sheet, Strip & Plate – 6Al 2Sn 4Zr-2Mo – Annealed AMS 4920 Forgings – 6Al-4V – Alpha Beta or Beta Processed – Annealed AMS 4921 Bars, Forgings & Rings – Annealed – 70,000 psi Yield AMS 4924 Bars, Forgings & Rings – 5Al-2.5Sn – Extra Low Interstitial, Annealed – 90,000 psi Yield AMS 4926 Bars & Rings – 5Al-2.5Sn – Annealed – 110,000 psi Yield AMS 4928 Bars & Forgings – 6Al-4V – Annealed – 120,000 psi Yield AMS 4930 Bars, Forgings & Rings – 6Al-4V – Extra Low Interstitial, Annealed AMS 4931 Bars, Forgings & Rings – 6Al-4V ELI, Duplex Annealed, Fractured Toughness AMS 4933 Extrusions & Flash Welded Rings – 8AI 1Mo 1V – Solution Heat Treated & Stabilized AMS 4934 Extrusions & Flash Welded Rings - 6Al-4V – Solution Heat Treated & Aged AMS 4935 Extrusions & Flash Welded Rings – 6Al-4V – Annealed, Beta Processed AMS 4936 Extrusions & Flash Welded Rings – 6Al-4V – Beta Processed AMS 4941 Tubing, Welded – Annealed – 40,000psi Yield AMS 4942 Tubing, Seamless – Annealed – 40,000 psi Yield AMS 4943 Tubing, Seamless – Annealed – 3.0Al 2.5V AMS 4944 Tubing, Seamless – hydraulic – 3.0Al 2.5V – Cold Worked, Stress Relieved AMS 4951 Wire, Welding – Commercially Pure AMS 4953 Wire, Welding – 5Al 2.5Sn AMS 4954 Wire, Welding –6Al 4V AMS 4955 Wire, Welding – 8Al 1Mo 1V AMS 4956 Wire, Welding – 6Al 4V – Extra Low Interstitial, Environment Controlled AMS 4957 Bars & Wire, 3Al-8V-6Cr-4Mo-4Zr, Consumable Electrode Melted, Cold Drawn AMS 4958 Bars & Rod – 3Al-8V-6Cr-4Mo-4Zr, Consumable Electrode Melted, Solution Heat Treated & Centerless Ground AMS 4959 Wire – 13.5V 11Cr 3Al – Spring Temper AMS 4965 Bars, Forgings & Rings – 6Al-4V – Solution & Precipitation Heat Treated AMS 4966 Forgings – 5Al-2.5Sn – Annealed – 110,000 psi Yield AMS 4967 Rings & Forgings – 6Al-4V – Annealed, Heat Treatable AMS 4970 Bars & Forgings – 7Al 4Mo – Solution & Precipitation Heat Treated AMS 4971 Bars, Forgings & Rings – 6Al-6V-2Sn – Annealed, Heat Treatable AMS 4972 Bars & Rings – 8Al-1Mo-1V – Solution Heat Treated & Stabilize AMS 4973 Forgings – 8Al 1Mo 1V - Solution Heat Treated & Stabilized AMS 4974 Bars & Forgings – 11Sn 5.0Zr 2.3Al 1.0Mo 0.21Si - Solution & Precipitation Heat Treated AMS 4975 Bars & Rings – 6Al-2Sn-4Zr-2Mo - Solution & Precipitation Heat Treated AMS 4976 Forgings - 6Al-2Sn-4Zr-2Mo - Solution & Precipitation Heat Treated AMS 4979 Bars, Forgings & Rings – 6Al-6V-2Sn - Solution & Precipitation Heat Treated AMS 4981 Bars & Forgings 6Al 2Sn 4Zr 6Mo - Solution & Precipitation Heat Treated AMS 4983 Forgings – 10V 2Fe 3Al – Solution Heat Treated & Aged Military Titanium Specifications Mil-T-9046H Titanium & Titanium Alloy Sheet, Strip & Plate Type I – Commercially Pure: Composition A – CP GR 2 (40 KSI) Composition B – CP GR 4 (70 KSI) Composition C – CP GR 3 (55 KSI) Type II – Alpha Alloys: Composition A - 5Al-2.5Sn Composition B - 5Al-2.5Sn ELI Composition F – 8Al-1Mo-1V Composition G – 6Al-2Cb-1Ta-.8Mo Type III – Alpha-Beta Alloys: Composition C – 6Al-4V Composition D – 6Al-4V ELI Composition E – 6Al-6V-2Sn Composition G – 6Al-4Sn-4Zr-2Mo Composition H – 6Al-4V SPL Type IV – Beta Alloys Composition A – 13Al-11Cr-3Al Composition B – 11.5Mo-6Zr-4.5Sn (Beta III) Composition C – 3Al-8V-6Cr-4Mo-4Zr (Beta C™)(10) MIL-T-9046J Titanium & Titanium Alloy Sheet , Strip & Plate Commercially Pure (CP CP-1 – Grade 4 (70 KSI) CP-2 – Grade 3 (55 KSI) CP-3 – Grade 2 (40 KSI) CP-4 – Grade 1 (25 KSI) Alpha Alloys (A) A-1 – 5Al-2.5Sn A-2 – 5Al-2.5Sn (ELI) A-3 – 6Al-2Cb-1Ta-.8Mo A-4 – 8Al-1Mo-1V Alpha-Beta Alloys (AB) AB-1 – 6Al-4V AB-2 – 6Al-4V (ELI) AB-3 – 6Al-6V-2Sn AB-4 – 6Al-2Sn-4Zr-2Mo AB-5 – 3Al-2.5V AB-6 – 8Mn Beta Alloys (B) B-1 – 13V-11Cr-3Al B-2 – 11.5Mo-6Zr-4.5Sn (Beta III) B-3 – 3Al-8V-6Cr-$Mo-$zr (Beta C™)(10) B-4 – 8Mo-8V-2Fe-3Al MIL-T-9047E Titanium & Titanium Alloy Bars & Reforging Stock Alpha Alloys Composition 1 – Unalloyed Composition 2 – 5Al-2.5Sn Composition 3 – 5Al-2.5Sn ELI Composition 5 – 5Al-1Mo-1V Alpha-Beta Alloys Composition 6 – 6Al-4V Composition 7 – 6Al-4V ELI Composition 8 - 6Al-6V-2Sn Composition 9 – 7Al-4Mo Composition 10 – 11Sn-5Zr-2Al-1Mo Composition 11 – 6Al-2Sn-4Zr-2Mo Composition 14 – 6Al-2Sn-4Zr-6Mo Beta Alloys Composition 12 – 13V-11Cr-3Al Composition 13 – 11.5Mo-6Zr-4.5Sn (Beta III) MIL-T-9047G Titanium & Titanium Alloy Bars & Reforging Stock, Aircraft Quality Commercially Pure TI-CP-70 (Grade 4) Alpha Alloys Ti – 5Al-2.5Sn Ti – 5Al-2.5Sn (ELI) 6Al-2Cb-1Ta-.8Mo 8Al-1Mo-1V Alpha-Beta Alloys Ti – 3Al-2.5V Ti – 6Al-4V Ti – 6Al-4V (ELI) Ti – 6Al-6V-2Sn Ti – 6Al-2Sn-4Zr-2Mo Ti – 6Al-2Sn-4Zr-6Mo Ti –7Al-4Mo Beta Alloys Ti – 8Mo-8V-2Fe-3Al Ti – 11.5Mo-6Zr-4.5Sn (Beta III) Ti – 3Al-8V-6Cr-4Mo-4Zr (Beta C™)(10) Ti – 13V-11Cr-3Al Imperial and Metric sizes available upon request.

QUALITU STANDARD MATERIAL NO. DC07 DIN EN 10130 1.0873 The super deep drawing grade DC07 is specified according to the standard DIN EN 10130, which focuses on cold-rolled flat products made of soft steels for cold forming. This standard ensures that the technical requirements and test methods for cold-rolled products are met, which are of great importance in various industrial applications, especially where the highest demands are placed on formability and surface quality. DC07 is a particularly low-carbon steel characterized by exceptional cold formability. The chemical composition of DC07 is strictly controlled to ensure its excellent mechanical properties. The carbon content in DC07 is typically a maximum of 0.01 %, while the manganese content is a maximum of 0.20 %. The addition of micro-alloyed elements such as titanium and niobium can further improve formability and strength. The mechanical properties of DC07 are characterized by a very low maximum yield strength of 120 MPa and a tensile strength of between 270 and 350 MPa. A particularly outstanding property of DC07 is its high elongation at break of at least 40 %, which underlines the excellent formability of the material. These properties make DC07 ideal for the production of complex components that require extremely high precision and surface quality, such as deep-drawn body parts in the automotive industry or highly complex components in the electronics industry. The DIN EN 10130 standard also specifies precise tolerances for dimensions, shape and surface finish. These tolerances are crucial to ensuring consistently high product quality and meeting the requirements of end users. The surface of the cold-rolled flat products can be supplied in various qualities, from matt to high-gloss, to meet the specific requirements of different applications. The DIN EN 10152 standard specifies electrolytically galvanized, cold-rolled steel flat products for cold forming, including the super deep-drawing grade DC07. This standard defines the requirements for the zinc coating and the basic mechanical properties of the base material. DC07, when electrolytically galvanized in accordance with DIN EN 10152, is given an additional corrosion protection layer of zinc. This layer protects the material from oxidative influences and significantly increases the service life of the components made from it. The zinc coating can be applied in various thicknesses, depending on the specific requirements of the application. Typical coating thicknesses range from 5 to 20 µm. The chemical composition and mechanical properties of the base material DC07 remain unchanged after galvanizing and meet the requirements of DIN EN 10130. DC07 therefore retains its exceptional cold formability and mechanical performance. The yield strength, tensile strength and elongation at break also remain in the same range as for non-galvanized DC07. In addition to mechanical performance, the quality of the zinc coating is of central importance. The DIN EN 10152 standard specifies the requirements for the uniformity of the coating, the adhesive strength of the zinc and the surface quality. These requirements ensure that the galvanized products offer high corrosion resistance and an aesthetically pleasing surface. The use of DC07 in accordance with DIN EN 10152 is widespread in the automotive industry, the construction industry and in the manufacture of household appliances, where improved corrosion resistance is required in addition to high formability. Electrolytic galvanizing offers optimum protection here without impairing the excellent mechanical properties of the base material. In summary, it can be said that the DC07 super deep-drawing grade offers a wide range of applications in accordance with both DIN EN 10130 and DIN EN 10152. While DIN EN 10130 focuses on excellent formability and surface quality, DIN EN 10152 supplements these properties with improved corrosion resistance thanks to the zinc coating. Both standards ensure that DC07 is a reliable and high-quality material for numerous industrial applications.

QUALITU STANDARD MATERIAL NO. DC07 DIN EN 10130 1.0873 The super deep drawing grade DC07 is specified according to the standard DIN EN 10130, which focuses on cold-rolled flat products made of soft steels for cold forming. This standard ensures that the technical requirements and test methods for cold-rolled products are met, which are of great importance in various industrial applications, especially where the highest demands are placed on formability and surface quality. DC07 is a particularly low-carbon steel characterized by exceptional cold formability. The chemical composition of DC07 is strictly controlled to ensure its excellent mechanical properties. The carbon content in DC07 is typically a maximum of 0.01 %, while the manganese content is a maximum of 0.20 %. The addition of micro-alloyed elements such as titanium and niobium can further improve formability and strength. The mechanical properties of DC07 are characterized by a very low maximum yield strength of 120 MPa and a tensile strength of between 270 and 350 MPa. A particularly outstanding property of DC07 is its high elongation at break of at least 40 %, which underlines the excellent formability of the material. These properties make DC07 ideal for the production of complex components that require extremely high precision and surface quality, such as deep-drawn body parts in the automotive industry or highly complex components in the electronics industry. The DIN EN 10130 standard also specifies precise tolerances for dimensions, shape and surface finish. These tolerances are crucial to ensuring consistently high product quality and meeting the requirements of end users. The surface of the cold-rolled flat products can be supplied in various qualities, from matt to high-gloss, to meet the specific requirements of different applications. The DIN EN 10152 standard specifies electrolytically galvanized, cold-rolled steel flat products for cold forming, including the super deep-drawing grade DC07. This standard defines the requirements for the zinc coating and the basic mechanical properties of the base material. DC07, when electrolytically galvanized in accordance with DIN EN 10152, is given an additional corrosion protection layer of zinc. This layer protects the material from oxidative influences and significantly increases the service life of the components made from it. The zinc coating can be applied in various thicknesses, depending on the specific requirements of the application. Typical coating thicknesses range from 5 to 20 µm. The chemical composition and mechanical properties of the base material DC07 remain unchanged after galvanizing and meet the requirements of DIN EN 10130. DC07 therefore retains its exceptional cold formability and mechanical performance. The yield strength, tensile strength and elongation at break also remain in the same range as for non-galvanized DC07. In addition to mechanical performance, the quality of the zinc coating is of central importance. The DIN EN 10152 standard specifies the requirements for the uniformity of the coating, the adhesive strength of the zinc and the surface quality. These requirements ensure that the galvanized products offer high corrosion resistance and an aesthetically pleasing surface. The use of DC07 in accordance with DIN EN 10152 is widespread in the automotive industry, the construction industry and in the manufacture of household appliances, where improved corrosion resistance is required in addition to high formability. Electrolytic galvanizing offers optimum protection here without impairing the excellent mechanical properties of the base material. In summary, it can be said that the DC07 super deep-drawing grade offers a wide range of applications in accordance with both DIN EN 10130 and DIN EN 10152. While DIN EN 10130 focuses on excellent formability and surface quality, DIN EN 10152 supplements these properties with improved corrosion resistance thanks to the zinc coating. Both standards ensure that DC07 is a reliable and high-quality material for numerous industrial applications.

Product Name: 8mm titanium plate Material: Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr12 etc. Standard: ASTM B265 ASME SB 265 Surface: Pickling, Polishing, Sand Blasting Technique:Rolled, Forged Unit Price: $15usd/kg-$48usd/kg Thickness: 0.5-100mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Product Introduction Titaniu plates and titanium alloy plates are mainly used to manufacture various containers, reactors, heat exchangers, distillation towers, pipes, pumps and valves in the petrochemical machinery manufacturing industry. Titanium can be used as a titanium cathode and condenser in power stations, as well as environmental pollution control devices. The hardness of steel is higher than that of titanium plate, but the specific strength or tensile strength of titanium alloy is higher than that of high-quality steel. Titanium alloy has good heat resistance, low temperature toughness and fracture toughness, so it is mostly used as aircraft engine parts and rocket and missile structural parts. Titanium alloy can also be used as fuel and oxidant storage tanks and high-pressure vessels. There are already automatic rifles, mortar seat plates and recoilless gun launch tubes made of titanium alloy. Product Name: 8mm titanium plate Material: Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr12 etc. Standard: ASTM B265 ASME SB 265 Surface: Pickling, Polishing, Sand Blasting Technique:Rolled, Forged Thickness: 0.5-60mm Length: 500-6000mm Or As You Require Width: 500-1000mm Or As You Require Status and specifications of titanium plates Grade Technique Status Thickness Gr1 Gr2 Gr3 Gr4 (pure titanium plate) Hot rolled Annealed 4.1-60mm Cold rolled Annealed 0.3-4mm Gr5 Gr7 Gr12 etc. (Titanium alloy plate) Hot rolled Annealed 4.1-60mm Cold rolled Annealed 0.8-4.0mm

Standard: ASTM B863 Material: Gr2 Unit Price: $25usd/kg-$60usd/kg Shape: Straight, Spool, Coil Diameter: 0.1-7.0mm Surface: Bright Titanium wire has low density but high strength-to-weight ratio. In addition, it is non-toxic, non-magnetic and corrosion resistant. All these unique properties make titanium wire widely used in titanium woven and knitted mesh, electroplating, titanium fastener forming, welding, medical equipment manufacturing, spectacle frames, jewelry design and many other key industries. Generally, users pay more attention to the chemical elements or impurities of titanium welding wire. For other applications, customer concerns will include surface condition, tolerance precision, tempering (hardness), continuous coil weight/dimensions, tensile strength/yield strength, etc. Our engineers will find you the most suitable solution for your specific job here. Product name Titanium Wire Grade Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr12, Gr23, Ti-15V-3Al-3Cr-3Sn (Ti-15333), Nitinol (Ni-Ti) Size 0.1-7.0mm Shape Straight, Spool, Coil Surface Polishing, Pickling Standard ASTM B863 (for general industry) AWS A5.16 (for welding) ASTM F67, F136 (for medical) Customized specification Certificates EN 10204 3.1 Third parts inspection - SGS, TUV, BV etc.

Product name:Titanium sheet Grades: Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr12, Gr23 Standard: ASTM B265/ASME B265 AMS 4911 ASTM F67 ASTM F136 Dimension： Thickness*Width:200-3000mm*Length:500-6000mm Supply status: Annealed(M) Package: Carton or plywood case. MTC: EN10204.3.1 certificate There is Grade 1, Grade 2, Grade 3, Grade4, Grade5, Grade 7, Grade 12 titanium plates in stock. Titanium plate is widely used in various fields, including metallurgy, electronics, medical, chemical, petroleum, medicine, aerospace, etc.. We offer competitive prices online, available incutting size as customers' requets. 1, Specifications Thickness range: 0.5mm-200mm Titanium coil plate/titanium coil strip: 0.1mm-0.5mm thick *1m/1.2m/1.5m wide. Standard plate: 0.5mm-20mm thick *1m*2m. Cold rolled plate: 1mm-4mm*1m*2m hot rolled plate: above 4mm thick wide and thick plate: above 5mm *2m*6m is a common specification, and specific specifications can also be customized according to customer requirements. 2, Material TA1 (Grade 1), TA2 (Grade 2), TA9 (Grade 7), TA10 (Grade 12), TA18 TC4 (Grade 5), TC6 and TC11 3.Standard dimension in stock: 1000 mm Width * 2000 mm Length 1500 mm Width* 6000 mm Length 2000 mm Width* 6000 mm Length 4,Surface:Pickled, polished, sand-blasted

Product Name:Titanium wire Standard: ASMT B863,AWS A5.16 Material: Gr1, Gr2 ,Gr3, Gr4,Gr5, Gr7,Gr12 Unit Price: $21.5usd/kg-$60usd/kg Shape: Straight, Spool, Coil Diameter: 0.8mm/1mm/1.2mm/1.6mm/2mm/2.4mm/3mm/3.2mm etc. Surface: Pickling,polishing,sand-blasting Anodizing with titanium wire has many advantages. Firstly, titanium wire is resistant to corrosion and has excellent mechanical properties, making it an ideal choice for anodizing applications. Secondly, the uniform thickness and high-quality oxide layer produced by anodizing with titanium wire ensures excellent surface finish and durability for the treated metal part. Thirdly, titanium wire is cost-effective and readily available, making it a popular choice for anodizing applications. Fourthly, anodizing with titanium wire is an environmentally friendly process as it does not involve any hazardous chemicals or by-products. Overall, anodizing with titanium wire offers numerous benefits, making it a preferred choice among manufacturers and industries for enhancing the appearance, durability, and performance of their products. Product Name: Titanium wire Standard: ASTM B863 Material: Gr1, Gr2 ,Gr3, Gr4,Gr5, Gr7,Gr12 Shape: Straight, Spool, Coil Diameter: 0.8mm/1mm/1.2mm/1.6mm/2mm/2.4mm/3mm/3.2mm etc. Surface: Pickling,polishing,sand-blasting Titanium wire manufacture is devided into two technique: Cold drawing and hot drawing. Dimension Tolerance of titanium wire: Diameter 0.1-0.3mm 0.3-0.8mm 0.8-2.0mm 2.0-6.0mm Tolerance +/- 0.025 +/-0.04 +/-0.05 +/-0.10 Length 200-500mm 500-1000mm 1000-2000mm &2000mm Tolerance +/-1.0 +/-1.5 +/-2.0 +/-2.5

Product Name: Titanium Rod Standard: ASTM B348 AMS 4928 Material: Grade 5 Unit Price: $15usd/kg- $30usd/kg Shape: Round, Square, Flat, Hex Diameter: 3-350mm Length: Max 6000mm Surface: Bright Product Introduction Grade 5 Titanium Rod Product Information of Grade 5 Titanium Rod Grade: GR1, GR2, GR4, GR5, GR7, GR12, GR23 Standard: ASTM B348, AMS 4928, ASTM F67,ASTM F136 Shape: Round, Square, Flat, Hex Diameter: 3-350mm Length: Max 6000mm Surface: Polishing, Pickling Condition: Annealed Feature: 1. Polished surface without any defects free from cracks no pitting. 2. Two ends flatting making sure length tolerance and good looking. Sizes of Grade 5 Titanium Rod in stock Dia 2mm 2.5mm 3.0mm 3.5mm 4.0mm 5.0mm 6.0mm 7.0mm 8mm 9mm 10mm 12mm 15mm 16mm 18mm 20mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm 65mm 70mm 75mm 80mm 85mm 90mm 100mm 105mm 110mm 120mm

Product Name: Titanium Bar Standard: ASTM B348 Material: GR1, GR2, GR5, GR7, GR12 Unit Price: $15usd/kg- $30usd/kg Shape: Round, Square, Flat, Hex Diameter: 6-350mm Length: Max 6000mm Surface: Bright Grade 2 Pure Titanium Rod Product Information Grade: GR1, GR2, GR4, GR5, GR7, GR12, GR23 Russian Grade: BT1-00,BT1-0,BT1-2 Standard: ASTM B348, AMS 4928, ASTM F67,ASTM F136 Diameter: 3-350mm Length: up to 6000mm Surface: Polished, Pickled Features: Polished surface with no defects, no cracks and no pitting. Tolerance Diameter(mm) h7 h8 h9 h10 h11 h12 Tolerance precision (um) 3~6 12 18 30 48 75 120 6~10 15 22 36 58 90 150 10~18 18 27 43 70 110 180 "h"stands for a tolerance range(-x,+0),on the contrary,"H"stands for a tolerance(-0,+X) Advantages 1. Equipment: We have Trimming machines, milling machines, annealing furnaces, shearing machines, bending machines, straightening machines, sandblasting machines, punching machines and forging hammers etc. 2. Product: We have sufficient inventory and accept customized product. We can also provide you with samples. 3. Quality: We have exported our titanium rod to many countries, including the US, Italy, Korea, Ukraine and Chile etc. The quality of our products is widely recognized. Quality Certificate is available. Third-party testing is also accepted, like TUV, SGS, BV etc. 4. Price: As a leading manufacturer of titanium products for more than 16 years, we know the market very well. We can provide you with competitive prices. 5. Payment: Flexible payment terms. TT, LC, Western Union, Paypal etc. are all acceptable. You can choose any convenient way. 6. Packaging: Usually plywood box for export, ensuring that the goods will not get damaged during the shipment. 7. Shipment: Various shipping methods. EXW, FOB, CIF etc. are all ok for us. 8. Service: Professional team. We have set up a service department.
